From the supplier

I Description of the machine

This paper taping machine is for taping insulation papers to flat copper/aluminum wire used for transformer windings.

The machine has two taping heads for taping max. 8 layers.

Suitable wire:

l Flat copper/aluminum wire
l Section area: 5~100mm2
l Lapping pitch: 10-32mm, step less adjustable
l Tapping head rated speed: 500-600rpm

Suitable insulation paper:

l Width: 10~32mm
l Thickness: 0.04~0.125mm
l Paper pad OD: 330mm
l Paper pad ID: 75mm

II Buildup of the line: comprised of one pay-off stand, main machine and one take-up stands.

2.1 Horizontal pay-off stand 1 set

l Max. load: 800kg
l Up/down: motor
l Clamping: shaft

2.2 Straightening device 1 set

l Straightening rollers: 5 pcs horizontal, 5 pcs vertical
l Diameter of straightening rollers: 47mm
l Roller distance: 70mm

2.3 Taping heads 2sets

l Suitable paper reel: OD 330mm, ID 76mm
l Quantity of paper reels: 4 for each taping head
l Taping angle adjustment: by guiding roller, 15-70 degree
l Taping pitch: 10-32mm, continuous adjustable
l Pitch excursion: +/-0.2mm
l Paper breaking detection: mechanical method, automatic
l Material of rollers touching paper: 45# steel, or stainless steel, or UHMWPE
l Rotating speed of taping head: 500-600rpm
l Transmission device: servo motor

2.4 Caterpillar type towing device 1 set

l Belt width:40mm
l Length lf caterpillar: 1120mm
l Belt material: rubber
l Hardness of belt: 85 degree
l Max. towing force: 500kgf
l Max. opening clearance: 40mm
l Towing power: from main machine
l Clamping type: pneumatic
l Synchronization: servo motor

2.5 Length measuring device, 1 set

l Encoder measuring length
l Automatic stop when reaching pre-set length

2.6 Take-up stands, horizontal type 1set

l Wire guiding method: lighting rod ordering
l Bobbin elevating: torque motor
l Wire traversing: servo motor
l Take up: inverter motor
l Installing bobbin: with pintail of bearing
l Max. bearing weight: 800kg

2.7 Electric control system:

l Main electric: Schneider/Omron
l PLC: Mitsubishi
l Servo motor: Mitsubishi
l Servo drive: Mitsubishi
l Touch screen display: Taping pitch, rotation and line speed

Materail of rollers(contact with kraft): Chrome coated steel, stainless steel, tough plastic.
