From the supplier
This machine is special for producing header pipes to be used in Parallel-flow mico-channel condensers or evaporators.
Main power of this machine is hydraulic and pneumatic, assisted by spraying lubricate. It is four-guide structure, simple and convenient operation & maintenance. By changing different piercing dies quickly, different header pipes can be produced:
The hydraulic system adopts big-flow plug-in valves, high speed, stable running.
The machine is PLC control, HMI operation. Manually inserting aluminum pipe onto core axis, pressing down start button, machine will automatically position, insert core axis, clamp, lubricate, punch, shock, draw core axis, raise and automatic release finished header pipe, unloading.
Equipped with light curtain protection system, operation is very safe.
Main technical data:
Item
Data
Machine code
JLG-Y900
Max. working force
60T
Pipe quantity can be produced one time
One
Suitable material
Aluminum or copper
Suitable pipe diameter and wall thickness
Φ30mm x (1.0~1.6)mm
Suitable pipe effective length
100~600mm
Pierced slot width and tolerance
1.0~3 ± 0.03 mm
Pierced slot length and tolerance
16~36 ± 0.03mm
Center distance between slots and tolerance
5~12 ± 0.05mm
Production speed
About 20 seconds per piece
Die changing speed
About 30 minutes
Hydraulic pressure
8~21MPa
Pneumatic pressure
0.5~0.8MPa
Hydraulic oil
ISO VG32 for winter; ISO VG46 for Summer
Lubricant oil
ISO VG22-32
Total motor power
7.2kW
Machine dimension
2800 x 2100 x 2750mm
Machine weight
Total 4200kg
