From the supplier
ZHC-700T Cold Chamber Die Casting Machine
I Description
ZHC series cold chamber die casting machine can be used to cast the aluminum alloy products.
II Features
2.1 Pull-bar structure and hydraulic lifting device are good for mold
2.2 The exclusively designed injection system is equipped with piston-type fast speed and intensifier accumulators.
2.3 Equipped with big-diameter logic valve and flow control valve, which can improve injection quality and keep the oil pressure stable.
2.4 Hydraulic gear-type mold adjustment structure is easy for operation.
2.5 Unique high speed die lock system helps to improve production efficiency.
2.6 With automatic lubrication system, you can adjust the lubrication period and oil volume, which can lengthen the working life of the machine.
2.7 Hydraulic system is equipped with high pressure and low pressure two pumps so as to save energy and improve efficiency.
2.8 Stable and high-performance injection system: slow speed phase; high speed phase; intensification speed phase.
2.9 Energy saving rate is 40%-70% higher; productivity is 4%-15% higher.
III Main technical data
ITEM
Unit
Data
DIE CLAMPING SYSTEM
Die clamping force
kN
7000
Die clamping stroke
mm
650
Ejection force
kN
315
Ejection stroke
mm
155
Die height (Min-Max)
mm
350-850
Platen size(H x V)
mm
1256x1360
Distance between tie bars
mm
800x800
INKECTION SYSTEM
Injection position
mm
0,-250
Injection stroke
mm
650
Casting force(Intensification)
kN
590
Plunger diameter
mm
80,90,100
Injection weight(AL)
kg
6.0,7.8,9.5
Casting pressure(Intensification)
MPa
117,92,75
Casting area
cm²
596,754,931
Max. casting area(40MPa)
cm²
1750
Diameter of plunger sleeve flange
mm
150
Height of plunger sleeve flange
mm
15
Plunger penetration
mm
290
Others
Driving motor
kW
37
Hydraulic working pressure
MPa
14
Oil tank capacity
L
1200
Machine dimension
mm
7580x2060x3150
Weight
T
27.5
* Dimension of the machine mentioned here excludes the separate electric cabinet.
IV Main configuration
- SIEMENS PLC S-7 200 from Germany
- Hydraulic components are YUKEN, REXROTH or VICKERS brands
- Hydraulic seals are SEALTECH from Hong Kong or VECO from France
- Main electric components are SCHNEIDER from China
