Horizontal transformer coil winding machine
NANTONG ZHENHUAN TRADE CO., LTD.
See what’s includedHide breakdown
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Horizontal transformer coil winding machine
NANTONG ZHENHUAN TRADE CO., LTD.See what’s includedHide breakdown
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 3500x1500mm
- Color: Blue
- Control type: PLC
- Certification: Other
- Layout: Vertical
- Customized: Customized
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
About this product
- Size: 3500x1500mm
- Color: Blue
- Control type: PLC
- Certification: Other
- Layout: Vertical
- Customized: Customized
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
Product details
| Size | 3500x1500mm |
|---|---|
| Color | Blue |
| Control type | PLC |
| Certification | Other |
| Layout | Vertical |
| Customized | Customized |
Product details
| Size | 3500x1500mm |
|---|---|
| Color | Blue |
| Control type | PLC |
| Certification | Other |
| Layout | Vertical |
| Customized | Customized |
From the supplier
Main technical data for horizontal transformer coil winding machine
Specification / Model
ZHR-1
ZHR-2
ZHR-3
ZHR-4
ZHR-5
ZHR-6
Height of clicker center (mm)
900
1000
1100
1400
1400
1800
Diameter of disc clicker (mm)
250
250
300
600
1000
1400
Rotating speed of clicker (rpm)
0-200
0-100
0-80
0-25
0-10
Max. Torque of clicker (N·m)
600
1000
2500
8000
15000
20000
Max. bearing weight (kg)
1000
1000
2000
5000
10000
15000
Motor power (kW)
3
3
5.5
7.5
11
15
Power supply
380V, 3 phase, 50Hz
ZHR-1 is suitable for winding coils for transformer max. 800kVA;
ZHR-2 is suitable for winding coils for transformers max. 3150KVA;
ZHR-3 is suitable for winding coils for transformers max. 8000KVA;
ZHR-4 is suitable for winding coils for transformers max. 25000KVA;
ZHR-5 is suitable for winding coils for transformers max. 90000KVA;
ZHR-6 is suitable for winding coils for transformers max. 500000KVA.
From the supplier
Main technical data for horizontal transformer coil winding machine
Specification / Model
ZHR-1
ZHR-2
ZHR-3
ZHR-4
ZHR-5
ZHR-6
Height of clicker center (mm)
900
1000
1100
1400
1400
1800
Diameter of disc clicker (mm)
250
250
300
600
1000
1400
Rotating speed of clicker (rpm)
0-200
0-100
0-80
0-25
0-10
Max. Torque of clicker (N·m)
600
1000
2500
8000
15000
20000
Max. bearing weight (kg)
1000
1000
2000
5000
10000
15000
Motor power (kW)
3
3
5.5
7.5
11
15
Power supply
380V, 3 phase, 50Hz
ZHR-1 is suitable for winding coils for transformer max. 800kVA;
ZHR-2 is suitable for winding coils for transformers max. 3150KVA;
ZHR-3 is suitable for winding coils for transformers max. 8000KVA;
ZHR-4 is suitable for winding coils for transformers max. 25000KVA;
ZHR-5 is suitable for winding coils for transformers max. 90000KVA;
ZHR-6 is suitable for winding coils for transformers max. 500000KVA.
