1. Introduction

ZH-FCS series CNC cold saw machine adopt HSS/TCT saw blade for the steel pipe cutting, racking, synchronization and return, automatically. Reasonable designs guarantee the machine stable and reliable running. Adopt numerical control system to tracking and cutting. Tracking and cutting process can be seen on the Human-machine Interface (HMI) and also setting parameters is available. The trolley installed tilt on the bed body guarantee the clamping device cutting more hasten. Realize high precision cutting, no burr, easy maintenance, and easy operation, etc.

II Technical Data:

2.1 Material: Low carbon steel

2.2 Pipe Size: Round Pipe, OD Max. 12.7-76.2mm

2.3 Pipe wall thickness: 0.8 – 3.2mm

2.4 Cutting Length: 3～32m (continuously adjustable)

2.5 Max speed ≤ 90m/min

2.6 Cutting Precision≤± 2mm

2.7 Requirement for line speed instability for rolling mill≤2%

III. Specification for Electrical Equipment

3.1 Control console   1 set

3.1.1 Button (French Schneider)

3.1.2 10″Crystal touch screen

3.2 Control Cabinet   1 set

3.2.1 11 KW servo motor driver (Japan YASKAWA)         1

3.2.2 15 KW AC sawing motor driver (Japan YASKAWA)     1

3.2.3 2.9 KW feeding servo motor driver (Japan YASKAWA)   1

3.2.4 CT-Ⅱ Motion controller (from the manufacturer)        1

3.2.5 Main low voltage components & parts (French Schneider)

3.3 Encoder (OMRON)   1pc

3.4 Approaching switch (OMRON)   4pcs

IV. Specification for mechanical equipment

4.1 Sawing car Drive motor: 11 KW (Servo motor, Japan YASKAWA)

4.2 Blade Feeding Motor: 2.9KW (Servo motor, Japan YASKAWA)

4.3 Sawing motor: 15KW (AC motor)

4.4 Horizontal Structure Lathe Bed, one set.

4.5 Inclined cart, one set.

4.6 Cutting Feed System (ball screw, linear guide Taiwan HIWIN)

4.7 Saw Blade Rotation System

4.5 Clamps: 2 sets (pneumatic clamping fixtures)

4.6 Cooling System: one set

 4.7 Speed Measuring Device: one set

 4.8 Saw Blade: 2 pieces OD450mm HSS
