MAXGE SGBL Residual Operated Current Ciruit Breaker RCBO
MAXGE ELECTRIC TECHNOLOGY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
MAXGE SGBL Residual Operated Current Ciruit Breaker RCBO
MAXGE ELECTRIC TECHNOLOGY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Plastic Copper Iron
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, Other European Countries, Others
- Made in: Zhejiang, China
About this product
- Materials: Plastic Copper Iron
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, Other European Countries, Others
- Made in: Zhejiang, China
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Color | White |
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Color | White |
From the supplier
Standard
EN/IEC 61009-1
Rated voltage
230VAC
Breaking capacity
6kA
Ambient temperature
-25℃~+45℃，Max.95%humidity
Protection
Ground fault,overcurrent and short circuit
Residual current off-time
≤0.1sec.
Rated current,In
3,6,10,16,20,25,32,40A
Type of trip Ground fault
Over current
Electronic/electro-magnetic
Thermal-magnetic
Operating,I△n
10,30,100,300mA
Protection degree
IP20
Characteristic
B.C
Terminal capacity
10mm2 flexible/16mm2 rigid
Rated residual current operted making & breaking capacity I△n
500A
Installation
35mm DIN rail
Rated residual non-operated current I△n
0.5I△n
Width
2 modules
Rated impulse withstand voltage Uimp
4000V
Type of werminal
Lug type and Pin type
Number of pole
1P+N
From the supplier
Standard
EN/IEC 61009-1
Rated voltage
230VAC
Breaking capacity
6kA
Ambient temperature
-25℃~+45℃，Max.95%humidity
Protection
Ground fault,overcurrent and short circuit
Residual current off-time
≤0.1sec.
Rated current,In
3,6,10,16,20,25,32,40A
Type of trip Ground fault
Over current
Electronic/electro-magnetic
Thermal-magnetic
Operating,I△n
10,30,100,300mA
Protection degree
IP20
Characteristic
B.C
Terminal capacity
10mm2 flexible/16mm2 rigid
Rated residual current operted making & breaking capacity I△n
500A
Installation
35mm DIN rail
Rated residual non-operated current I△n
0.5I△n
Width
2 modules
Rated impulse withstand voltage Uimp
4000V
Type of werminal
Lug type and Pin type
Number of pole
1P+N
