AFDD Arc fault detection device
MAXGE ELECTRIC TECHNOLOGY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
AFDD Arc fault detection device
MAXGE ELECTRIC TECHNOLOGY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Plastic Copper Iron
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
About this product
- Materials: Plastic Copper Iron
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Color | White |
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Color | White |
From the supplier
Arc fault circuit breakers are also known as arc fault inspection devices. AFDD is mainly to reduce the risk of electrical fire caused by series arc or parallel arc faults between live conductors. , It can check the electric arc fault, disconnect the power circuit before the electric fire occurs, and effectively avoid the electric fire caused by the arc fault. AFDD can also be combined with residual current protection appliances and overcurrent protection appliances to form a multi-purpose protection device.
Product descriptionAFDD+eRCBOConforms to standardIEC/BS EN 62606, IEC/BS EN 61009-1Technical SpecificationsRated Current: 6-32AFrequency: 50/60HzSensitivity: 30,100,300mAApplicationConsumer unitType & mounting arrangementDin-RaileRCBO TypeA & ACOperational Voltage Range180V to 264VPole1P+N (with switched neutral)Insulation Voltage (V)500Impulse Voltage (V)4000Protection degreeIP20 /IP40 (Terminals/Housing)Rated nominal breaking capacity lcn (A)6kARated service breaking capacity Ics (A)6kARated residual breaking/making capacity I△m (kA)3kATripping CurveB and CEnduranceMechanical operations>10000Electrical operations≥1200Quality mark on productSEMKO,CEFrom the supplier
Arc fault circuit breakers are also known as arc fault inspection devices. AFDD is mainly to reduce the risk of electrical fire caused by series arc or parallel arc faults between live conductors. , It can check the electric arc fault, disconnect the power circuit before the electric fire occurs, and effectively avoid the electric fire caused by the arc fault. AFDD can also be combined with residual current protection appliances and overcurrent protection appliances to form a multi-purpose protection device.
Product descriptionAFDD+eRCBOConforms to standardIEC/BS EN 62606, IEC/BS EN 61009-1Technical SpecificationsRated Current: 6-32AFrequency: 50/60HzSensitivity: 30,100,300mAApplicationConsumer unitType & mounting arrangementDin-RaileRCBO TypeA & ACOperational Voltage Range180V to 264VPole1P+N (with switched neutral)Insulation Voltage (V)500Impulse Voltage (V)4000Protection degreeIP20 /IP40 (Terminals/Housing)Rated nominal breaking capacity lcn (A)6kARated service breaking capacity Ics (A)6kARated residual breaking/making capacity I△m (kA)3kATripping CurveB and CEnduranceMechanical operations>10000Electrical operations≥1200Quality mark on productSEMKO,CEAbout the supplier
