Circuit breakers
Circuit Breaker
MAXGE ELECTRIC TECHNOLOGY CO.,LTD10/10 fairsManufacturerModel EPBR-63H
New for the 140th FairGreen / low-carbon
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Circuit Breaker
MAXGE ELECTRIC TECHNOLOGY CO.,LTD10/10 fairsManufacturerModel EPBR-63H
New for the 140th FairGreen / low-carbon
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Plastic Copper Iron
- Size: 35.6*83.6*76.8
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
About this product
- Materials: Plastic Copper Iron
- Size: 35.6*83.6*76.8
- Color: White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Size | 35.6*83.6*76.8 |
| Color | White |
Product details
| Materials | Plastic Copper Iron |
|---|---|
| Size | 35.6*83.6*76.8 |
| Color | White |
From the supplier
Standard
EN/IEC61009-1
Characteristic
B.C Curve
Breaking capacity
6KA,10KA
Electrical endurance
4000
Number of poles
1P+N(1module)
Mechanical endurance
10000
Rated current In 6,10,16,20,25,32,40A
Ambient tenperature(ºC)
-25ºC~+45ºC,Max.95%humidity
Rated voltage
240VAC
Connection terminal
Flexible conductor 16mm²
Rigid conductor 25mm²
Rated Tripping Current
10,30,100,300mA
Type of terminal
Lug type and Pin type
Residual current off time
≤0.1s Width 25mm
EN/IEC61009-1
Characteristic
B.C Curve
Breaking capacity
6KA,10KA
Electrical endurance
4000
Number of poles
1P+N(1module)
Mechanical endurance
10000
Rated current In 6,10,16,20,25,32,40A
Ambient tenperature(ºC)
-25ºC~+45ºC,Max.95%humidity
Rated voltage
240VAC
Connection terminal
Flexible conductor 16mm²
Rigid conductor 25mm²
Rated Tripping Current
10,30,100,300mA
Type of terminal
Lug type and Pin type
Residual current off time
≤0.1s Width 25mm
From the supplier
Standard
EN/IEC61009-1
Characteristic
B.C Curve
Breaking capacity
6KA,10KA
Electrical endurance
4000
Number of poles
1P+N(1module)
Mechanical endurance
10000
Rated current In 6,10,16,20,25,32,40A
Ambient tenperature(ºC)
-25ºC~+45ºC,Max.95%humidity
Rated voltage
240VAC
Connection terminal
Flexible conductor 16mm²
Rigid conductor 25mm²
Rated Tripping Current
10,30,100,300mA
Type of terminal
Lug type and Pin type
Residual current off time
≤0.1s Width 25mm
EN/IEC61009-1
Characteristic
B.C Curve
Breaking capacity
6KA,10KA
Electrical endurance
4000
Number of poles
1P+N(1module)
Mechanical endurance
10000
Rated current In 6,10,16,20,25,32,40A
Ambient tenperature(ºC)
-25ºC~+45ºC,Max.95%humidity
Rated voltage
240VAC
Connection terminal
Flexible conductor 16mm²
Rigid conductor 25mm²
Rated Tripping Current
10,30,100,300mA
Type of terminal
Lug type and Pin type
Residual current off time
≤0.1s Width 25mm
