Sell High Quality Sand Pumping Machine Suction Pump

More details please contact:

Maggie Wu

Whatsapp: +86 17806285992

Email: oceanpump14@tsbeng.com

Product Description

Sand pumping machine suction pump can pumping sand and gravel equipped on dredger ship or boat. Our sand pumping machine suction pump is passed through the trial test and industrial operation test, it has the  characteristics of energy saving, high hydraulic efficiency, good wear resistance and reliable operation in the delivery of solid particles. The sand pumping machine suction pump is suitable for inland river dredging, coastal embankment , coal mines, power plants and other enterprises to transport solid particles containing slurry, medium particles up to 50-80 mm. The dredger sand pump is also used to pump sand or slurry in the river, lake, sea and reservoir, land reclamation , pumping iron ore,  gold sand.

Specification

Description diagram of the sand pumping machine suction pump



sand pumping machine suction pump Specifications



TypeFlowHeadRotation rateDiesel engineImpeller diameterDiameter(inch)(m³/h)(m)(r/min)(hp)(mm)InletOutlet200PNS-305404898018055086410287307586250PNS-248503898025055010862021730122108250ND-2280022730150-2506201010250PNS-30111030730185-250650108250PNS-35145035730250670108350PNS-24165024730250-3005601412350PNS-35180035730350-4086901412400PNS-30220030730408-4506501614450PNS-30260030700520-6007201816500PNS-40285038700580-7207502016350DN-50240050550720-8189501614450DN-60315042550540-72010001816500DN-30392028550818-10009002016550DN-60400060500818-120010002218

The information in the table is not complete. Please click here to get more detailed data.

Features

1.Material : Using the cast iron ,cast steel or high wear resistant and strong corrosion resistance chrome alloy to make the over -flow part .

2.Long-term bearing life .The bearing assembly is composed of large diameter shaft and short overhang.

3.With distinctive innovation in hydraulic and structural design.

4.Large dredging depth, high density of dredging mud, good NPSH (net positive suction head)and strong suction lift ability.

5. the suction depth up to 35 meter under water, discharge head up to 60 meter and discharge distance up to 1000 meter-1500 meter without boost pump. The gravel size allow to pass through up to 80mm.

Application

sand pumping machine suction pump can be installed on dredger, ship, boat for sand and gravel pumping. it has the  characteristics of energy saving, high hydraulic efficiency, good wear resistance, reliable operation in the delivery of solid particles.

Successful cases

sand pumping machine suction pump is a hot sale and cost effective sand pumping machine suction pumping machine which can be installed on land or equipped on sand dredger. Our sand pumping machine suction pump has passed through the trial test and industrial operation test,  it has the characteristics of energy saving, high hydraulic efficiency, good wear resistance and reliable operation. The sand pumping machine suction pump is suitable for inland river dredging, coastal embankment, coal mines, power plants and other enterprises to transport solid particles containing slurry, medium particles up to 50-80 mm. The kind of sand pump is also used to pump sand or slurry in the river, lake, sea and reservoir, land reclamation, pumping iron ore, gold sand.

sand pumping machine suction pump designed by OCEAN Pump is used for dredging at the beginning. The configuration of sand suction and discharge pipeline is between simple sand pump and heavy duty sand pump. It is usually equipped on cutter suction dredger or mud unloading ship. Bolder axle, heavy bearing, water-cooled bearing box, three-blade impeller, four-blade impeller, vaneless impeller, open impeller can be matched for 14 inch sand pumping machine suction pump.

On July 4, 2019, a customer from Jiangsu visited OCEAN Pump. The customer has a bucket wheel dredger equipped with a 14 inch iron cast sand pump. The effect is good but over-current parts wears quickly. The customer saw 14 inch sand pumping machine suction pumps produced by OCEAN Pump near his construction site. The over-current components of the sand pumping machine suction pumps are made of high-chromium alloy. The service life is about ten times longer than ordinary cast iron sand pumps’. The customer came to OCEAN Pump and hoped to buy one set to replace it.

Through simple communication, OCEAN Pump engineers selected the 350 PNS-35 sediment removal pump to equip on the customer’s bucket wheel dredger. At the same time, the customer required two high-pressure water pumps, OCEAN Pump prepared water pumps and sand pumping machine suction pump for customer.

14 inch sand pumping machine suction pump performance parameters

Model

350 PNS-35

Flow rate

1800 m³/h

Lift

35 m

Matching diesel engine

450 hp

Speed

730 rpm
