FE7043WE-4.3 inch HMI
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
FE7043WE-4.3 inch HMI
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Size: Touch screen:4.3 inch
- Color: Black
- Structure: Other
- Customized: Non-Customized
- Mathematical model: Other
- Material: Other
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Other European Countries
About this product
- Size: Touch screen:4.3 inch
- Color: Black
- Structure: Other
- Customized: Non-Customized
- Mathematical model: Other
- Material: Other
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Other European Countries
Product details
| Size | Touch screen:4.3 inch |
|---|---|
| Color | Black |
| Structure | Other |
| Customized | Non-Customized |
| Mathematical model | Other |
| Material | Other |
| Signal | Other |
| Task | Program |
| Function | Monitoring |
From the supplier
FE7000 series, a new generation of human-machine interface. Continues the high cost-effectiveness of the FE6000 series, with industrial ABS plastic casing, high adaptability and reliability; The new rear
cover mold setting optimizes the rear cover design based on the FE6000 series, removes the small cover design, and improves the overall design feel of the product. There are also multiple resolution
models available to meet the needs of different application scenarios.
FE7043WE is a traditional HMI product that uses 1G, A7 processors,with cost-effective advantage.
FEATURES FE7043WE Display 4.3" 16:9 TFT LCD LCD Viewing Angles(T/B/L/R) 80'/80'/80'/80' Resolution 800×480 Colors 16-bit Brightness 250 cd/m² Touch Panel 4-wire resistive touchscreen CPU 1GHz, Dual-core Cortex-A7 Storage 128 MB DDR3+128 MB Flash Ethernet Port 1*RJ45,based on 10/100Mbps USB Port 1*Type-C OTG Program Download Method USB slave/Flash drive Serial Port COM1: RS232/RS485/RS422, COM2: RS485, COM3: RS232 Rated Power <5W Rated Voltage DC24V,Working range:DC 9V-28V Power Protection Lightning surge protection Power Interruption Tolerance <5mS Certification CE, RoHS Operating Temperature 0-50℃ Storage Temperature -20-60℃ UV Resistance Not for use in high UV environments Environmental Humidity 10-90%RH(Non-condensing) Vibration Endurance 10-25 Hz (X,Y,Z direction, 2G/30 min) Protection Level Front: IP65(NEMA panel), Rear: IP20 Enclosure Material Engineering plastic, gray Cutout Size 132mm×80mm Dimensions 138mm×86mm×32mm Weight About 300g
About the supplier
Main products: PLC Programmable Controller Systems and Software, Human-Machine Interfaces, Servo Motors and Drives
- ✓Exhibited at 5 recent Canton Fairs
- ✓Manufacturer
- ✓Founded 2010
- ✓Canton Fair Premium Supplier
- ✓National high-tech enterprise
- ✓1 certificate on file
- Exhibited at 5 recent Canton Fairs
- Manufacturer
- Founded 2010
- Canton Fair Premium Supplier
