Arc Fault Detector Audible or Visual Alarm AC 220V 2P 10~40A 50Hz
Adidi Electric(Suzhou)Co.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Arc Fault Detector Audible or Visual Alarm AC 220V 2P 10~40A 50Hz
Adidi Electric(Suzhou)Co.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: plastic
- Size: mm
- Color: grey
- Arc-extinguishing medium: Other
- Installation: Other
- Certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Suzhou, Jiangsu, China
About this product
- Materials: plastic
- Size: mm
- Color: grey
- Arc-extinguishing medium: Other
- Installation: Other
- Certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Suzhou, Jiangsu, China
Product details
| Materials | plastic |
|---|---|
| Size | mm |
| Color | grey |
| Arc-extinguishing medium | Other |
| Installation | Other |
| Certification | Other |
| Poles number | Other |
Product details
| Materials | plastic |
|---|---|
| Size | mm |
| Color | grey |
| Arc-extinguishing medium | Other |
| Installation | Other |
| Certification | Other |
| Poles number | Other |
From the supplier
Arc Fault Detector ADDA-40 can constantly and effectively detect and identify arc faults happened to electrical circuit connected in series, in parallel and to earth as a result of disabled insulation layer due to aging, damaging or loosen terminal connection. Upon detecting arc fault in its connected circuit, the device immediately gives out both audible or visual alarm and trigger its connected fire protection device to trip and communicate with its upstream server to achieve remote monitoring. ADDA-40 can be installed separately for protection of relatively independent power distribution cabinet or be incorporated in fire monitoring and alarm system.
Technical Parameters
ContentTechnical ParametersRated voltage Ue, VAC 220±15%Rated frequency, Hz50Rated current In, A10, 16, 20, 25, 32, 40Alarm modeaudible and visual alarmBuzzer≥70dBCommunication protocolCAN bus, RS485Bus typetwisted pair cable ZR-VS-2×1.5Relay socketfor relay 3A/220V~, passive typeAmbient temperature, ℃-10~+40Relative humidity≤90%MountingDIN rail 35mmStandardGB14287.4-2014Type test reportNo.DZ2018200449From the supplier
Arc Fault Detector ADDA-40 can constantly and effectively detect and identify arc faults happened to electrical circuit connected in series, in parallel and to earth as a result of disabled insulation layer due to aging, damaging or loosen terminal connection. Upon detecting arc fault in its connected circuit, the device immediately gives out both audible or visual alarm and trigger its connected fire protection device to trip and communicate with its upstream server to achieve remote monitoring. ADDA-40 can be installed separately for protection of relatively independent power distribution cabinet or be incorporated in fire monitoring and alarm system.
Technical Parameters
ContentTechnical ParametersRated voltage Ue, VAC 220±15%Rated frequency, Hz50Rated current In, A10, 16, 20, 25, 32, 40Alarm modeaudible and visual alarmBuzzer≥70dBCommunication protocolCAN bus, RS485Bus typetwisted pair cable ZR-VS-2×1.5Relay socketfor relay 3A/220V~, passive typeAmbient temperature, ℃-10~+40Relative humidity≤90%MountingDIN rail 35mmStandardGB14287.4-2014Type test reportNo.DZ2018200449About the supplier
Main products: AC breaker, Circuit breaker, Small breaker ( low-voltage apparatus), Switch disconnector/Circuit breaker, Surge protector, Earth Leakage Circuit Breaker, GFCI (Ground Fault Circuit Interrupter), Signal Lamp Circuit Breaker
