30kV Medium voltage power cable
shanghai qifan cable co.,ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
30kV Medium voltage power cable
shanghai qifan cable co.,ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Materials: Copper
- Size: 25mm2 to 800mm2
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
About this product
- Materials: Copper
- Size: 25mm2 to 800mm2
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shanghai, China
Product details
| Materials | Copper |
|---|---|
| Size | 25mm2 to 800mm2 |
Product details
| Materials | Copper |
|---|---|
| Size | 25mm2 to 800mm2 |
From the supplier
1.Product Application
To be used for power distribution in medium voltage, as transformer feeders in substations. In power plants, industrial and operation installations, in residential areas and mining installations, in dry or wet locations, fixed installed in air, directly buried in the ground or in ducts, where require higher mechanical protection.
2.Standard
Cable design: IEC 60502-2 or custom cable
Conductor: IEC 60228
3.Voltage test
AC Voltage Withstand: 3.5U0/5min,No breakdown
Partial discharge test:1.73U0,≯10pc
4.Temperature characteristics:
Conductor operating temperature: -15℃~90℃
Min. temperature laying condition: 0℃
Conductor emergency operating temperature: 105℃
Conductor short-circuit operating temperature (5s): 250℃
From the supplier
1.Product Application
To be used for power distribution in medium voltage, as transformer feeders in substations. In power plants, industrial and operation installations, in residential areas and mining installations, in dry or wet locations, fixed installed in air, directly buried in the ground or in ducts, where require higher mechanical protection.
2.Standard
Cable design: IEC 60502-2 or custom cable
Conductor: IEC 60228
3.Voltage test
AC Voltage Withstand: 3.5U0/5min,No breakdown
Partial discharge test:1.73U0,≯10pc
4.Temperature characteristics:
Conductor operating temperature: -15℃~90℃
Min. temperature laying condition: 0℃
Conductor emergency operating temperature: 105℃
Conductor short-circuit operating temperature (5s): 250℃
About the supplier
Main products: Household cable, Cables
- ✓Exhibited at 6 recent Canton Fairs
- ✓Industry and Trade Company
- ✓Founded 1994
- ✓Canton Fair Premium Supplier
- ✓1 certificate on file
Light & Electrical exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 6 recent Canton Fairs
- Industry and Trade Company
- Founded 1994
- Canton Fair Premium Supplier
