0.6/1kV PVC Insulation Cable
Zhengzhou Jinhang High-tech CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
0.6/1kV PVC Insulation Cable
Zhengzhou Jinhang High-tech CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Copper and Aluminium
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Copper and Aluminium
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Copper and Aluminium |
|---|
Product details
| Materials | Copper and Aluminium |
|---|
From the supplier
The PVC insulated power cable and fire resistant cable are suitable for fixed laying in power transmission and distribution lines with A.C.50HZ and voltage rating of up to or including 6KV.
Performance Characteristics:
1. The long-term permissible operation temperature of conductor shall not be higher than 70℃
2. Conductor maximum short circuit (not more than 5 seconds) temperature shall not be higher than 160℃
3.The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0℃
4. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardant.
5.Light weight, perfect bending properties, installed and maintained easily and conveniently.
Voltage rating：0.6/l kV，3.6/6kV
Conductors : copper or aluminum
Number of cable cores: one core (Single core), two cores (Double cores), three cores, four cores (Four Equal-section-area cores or three equal-section-area smaller section area neutral cores), five cores (Five equal-section-area cores or three equal-section-area cores and two smaller section area neutral cores),
we provide armored type and without armored type for the cables stated above.
Our company has been carrying out Chinese national standard GB12706 and GB12666.6 (equivalent to 1EC60502 and IEC60331) for PVC insulated power cable and fire resistant cable needed by domestic customer, and for foreigner customers we can manufacture in accordance with IEC， BS, DIN， ASTM and other countries standards. In addition, we can design and manufacture PVC insulated power cable with special characteristics according to needs of customers.
From the supplier
The PVC insulated power cable and fire resistant cable are suitable for fixed laying in power transmission and distribution lines with A.C.50HZ and voltage rating of up to or including 6KV.
Performance Characteristics:
1. The long-term permissible operation temperature of conductor shall not be higher than 70℃
2. Conductor maximum short circuit (not more than 5 seconds) temperature shall not be higher than 160℃
3.The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0℃
4. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardant.
5.Light weight, perfect bending properties, installed and maintained easily and conveniently.
Voltage rating：0.6/l kV，3.6/6kV
Conductors : copper or aluminum
Number of cable cores: one core (Single core), two cores (Double cores), three cores, four cores (Four Equal-section-area cores or three equal-section-area smaller section area neutral cores), five cores (Five equal-section-area cores or three equal-section-area cores and two smaller section area neutral cores),
we provide armored type and without armored type for the cables stated above.
Our company has been carrying out Chinese national standard GB12706 and GB12666.6 (equivalent to 1EC60502 and IEC60331) for PVC insulated power cable and fire resistant cable needed by domestic customer, and for foreigner customers we can manufacture in accordance with IEC， BS, DIN， ASTM and other countries standards. In addition, we can design and manufacture PVC insulated power cable with special characteristics according to needs of customers.
