Rated voltage 0.6/1kV copper core PVC insulated PVC sheathed power cable.
shanghai qifan cable co.,ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Rated voltage 0.6/1kV copper core PVC insulated PVC sheathed power cable.
shanghai qifan cable co.,ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
From the supplier
Cable Mode
VV-0.6/1kV
Application scope
This product is suitable for use in AC 50Hz circuits with a rated voltage of not more than 0.6/1kV, for the purpose of power transmission and distribution.
Cable Structure
Conductor
Class 1 or Class 2 copper conductor
Insulation
（PVC）
Filling （optional）
Polypropylene mesh rope
Sheath
（PVC）
Standard
GB/T 12706.1，IEC 60502-1
Technical parameters
Rated voltage (U0/U)
0.6/1kV
Maximum system voltage (Um):
1.2kV
Temperature rating
Conductor maximum operating temperature: +70℃
Ambient temperature for usage: -20℃~+45℃
Cable laying temperature: Not lower than 0℃ (When the ambient temperature is below 0℃, the cable should be preheated)
Minimum bending radius:
Single-core cable: 20D
Multi-core cable: 15D
Note: D stands for the actual outer diameter of the cable
Installation methods:
Conduit laying, shallow groove laying, cable trench laying, tunnel laying, sandwich laying, support-type overhead laying, suspension-type overhead laying, etc.
Product certification
From the supplier
Cable Mode
VV-0.6/1kV
Application scope
This product is suitable for use in AC 50Hz circuits with a rated voltage of not more than 0.6/1kV, for the purpose of power transmission and distribution.
Cable Structure
Conductor
Class 1 or Class 2 copper conductor
Insulation
（PVC）
Filling （optional）
Polypropylene mesh rope
Sheath
（PVC）
Standard
GB/T 12706.1，IEC 60502-1
Technical parameters
Rated voltage (U0/U)
0.6/1kV
Maximum system voltage (Um):
1.2kV
Temperature rating
Conductor maximum operating temperature: +70℃
Ambient temperature for usage: -20℃~+45℃
Cable laying temperature: Not lower than 0℃ (When the ambient temperature is below 0℃, the cable should be preheated)
Minimum bending radius:
Single-core cable: 20D
Multi-core cable: 15D
Note: D stands for the actual outer diameter of the cable
Installation methods:
Conduit laying, shallow groove laying, cable trench laying, tunnel laying, sandwich laying, support-type overhead laying, suspension-type overhead laying, etc.
Product certification
