About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 1830*1760*1700
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 1830*1760*1700
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 1830*1760*1700 |
| Color | Custom color |
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 1830*1760*1700 |
| Color | Custom color |
From the supplier
XQ6432 universal milling machine
It is a new series of conventional machines equipped with servo motor and drives for 3 working feeds,
which is a patented product of our factory:
Main Features :
1.XL6230 Vertical Lifting Milling Machine with universal milling head which can swivel 360 degree
2.Table 3 axes are controlled by one servo motor, toque large, energy efficiency, safe and reliable.
3.Hardened on x, y, z axis,rectangular guideway, stable, good rigidity.
Specification
Specifications
Unit
XL6230
XL6230A
XL6230B
XL6230C
Table size
mm
1270*300
1370*300
1270*300
1370*300
T-slots(NO./width/pitch)
mm
3*14*80
Max table travel - X/Y/Z
mm
720/300/400
820/300/400
900/380/400
1000/380/400
Spindle taper
-7:24 ISO40
Distance between spindle nose and table surface
mm
100-500
Spindle speed range
r.p.m
11 steps 45-1660
Max swivel angle of milling head
-360°
Table feed(X/Y/Z)
mm/min
XY:30-830 Z:23-625
Table rapid speed
1335/1335/1000
Main motor power
Kw
2.2 or 3
Torque of X/Y/Z axis AC servo motor
Nm
10
Overall size
mm
1730*1760*1700
1830*1760*1700
1730*1760*1700
1830*1760*1700
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
From the supplier
XQ6432 universal milling machine
It is a new series of conventional machines equipped with servo motor and drives for 3 working feeds,
which is a patented product of our factory:
Main Features :
1.XL6230 Vertical Lifting Milling Machine with universal milling head which can swivel 360 degree
2.Table 3 axes are controlled by one servo motor, toque large, energy efficiency, safe and reliable.
3.Hardened on x, y, z axis,rectangular guideway, stable, good rigidity.
Specification
Specifications
Unit
XL6230
XL6230A
XL6230B
XL6230C
Table size
mm
1270*300
1370*300
1270*300
1370*300
T-slots(NO./width/pitch)
mm
3*14*80
Max table travel - X/Y/Z
mm
720/300/400
820/300/400
900/380/400
1000/380/400
Spindle taper
-7:24 ISO40
Distance between spindle nose and table surface
mm
100-500
Spindle speed range
r.p.m
11 steps 45-1660
Max swivel angle of milling head
-360°
Table feed(X/Y/Z)
mm/min
XY:30-830 Z:23-625
Table rapid speed
1335/1335/1000
Main motor power
Kw
2.2 or 3
Torque of X/Y/Z axis AC servo motor
Nm
10
Overall size
mm
1730*1760*1700
1830*1760*1700
1730*1760*1700
1830*1760*1700
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
