From the supplier
XK715 CNC Bed-type Milling Machine
1.Machine Features
(1). Variable spindle speeds in 2 steps
(2). Ball screws on X,Y and Z axes
(3). Servo motor on X, Y and Z axes
(4).XK715 3 axis 4 axis cnc milling machine is equipped with 3-axis digital readout system. It improves the machining accuracy and processing convenience.
Specification
Specifications
Unit
XK715
Spindle hole taper
mm
7:24 ISO50
Spindle speed range
r/min
Variable 6-300,30-1500
Distance between spindle axis and column guideway
mm
610
Distance between spindle nose and table surface(V)
mm
0-650
Distance between spindle axis and table surface(H)
mm
8-660
Table size
mm
2100*500
T slots
mm
4/20/100
Table travel-X
mm
1500
Table travel-Y
mm
650
Table feed-X/Y
mm/min
2.5-3000
Table feed-Z
mm/min
2.5-2500
Table rapid feed X/Y/Z
mm/min
6000/6000/3000
Main motor power
Kw
11
Torque of X/Y/Z axis AC servo motor
Nm
18/23/18
Cooling pump motor power
w
90
Overall size
mm
3220*2420*2800
weight
kg
7300
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
