VMC750 CNC Vertical Machining Center
TENGZHOU XILI MACHINE TOOL CO.,LTD.
See what’s includedHide breakdown
- FOB goods (100)
- $2,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $87,500
- Section 301 tariff (25.0%)
- $625,000
- Customs fees (MPF/HMF)
- $3,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $2,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $87,500
- Section 301 tariff (25.0%)
- $625,000
- Customs fees (MPF/HMF)
- $3,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
VMC750 CNC Vertical Machining Center
TENGZHOU XILI MACHINE TOOL CO.,LTD.See what’s includedHide breakdown
- FOB goods (100)
- $2,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $87,500
- Section 301 tariff (25.0%)
- $625,000
- Customs fees (MPF/HMF)
- $3,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $2,500,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $87,500
- Section 301 tariff (25.0%)
- $625,000
- Customs fees (MPF/HMF)
- $3,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from your agent uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2260*2700*2450
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2260*2700*2450
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2260*2700*2450 |
| Color | Custom color |
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2260*2700*2450 |
| Color | Custom color |
From the supplier
VMC750 CNC Vertical Machining Center
- Brand of Main Component:
1.Ball screw: Taiwan HIWIN
2.Linear guideway: Taiwan HIWIN/PMI
3.Bearing: NSK
4.Spindle: Taiwan POSA/ROYAL
5.eletronic component: Schneider
6.Central lubrication : Japan HERG
7.Tool magazine: Taiwan Deta
Specification
Specification
Unit
VMC750
Table size
mm
500*900
Table travel X、Y、Z
mm
700、500、500
Distance between spindle and table surface
mm
120-620
Spindle center to column surface
mm
560
Rapid feed speed X
m/min
36/48
Rapid feed speed Y
m/min
36/48
Rapid feed speed Z
m/min
32
Cutting feed rate
mm/min
1-12000
Max table load
Kg
400
T-slot (N/W/D)
3/18/125
Spindle speed range
rpm
8000
Spindle diameter
mm
120
Spindle taper
/
BT40
Spindle motor power
Kw
5.5
Magazine capacity
T
20
Tool magazine type
Disc type
Max tool diameter
mm
Φ80-150/80-130
Max tool length
mm
300
Max tool weight
kg
6/7
Positioning accuracy
mm
±0.005
Repeatabiblity
mm
±0.003
Overall size
mm
2260*2700*2450
Net weight
kg
4200
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
From the supplier
VMC750 CNC Vertical Machining Center
- Brand of Main Component:
1.Ball screw: Taiwan HIWIN
2.Linear guideway: Taiwan HIWIN/PMI
3.Bearing: NSK
4.Spindle: Taiwan POSA/ROYAL
5.eletronic component: Schneider
6.Central lubrication : Japan HERG
7.Tool magazine: Taiwan Deta
Specification
Specification
Unit
VMC750
Table size
mm
500*900
Table travel X、Y、Z
mm
700、500、500
Distance between spindle and table surface
mm
120-620
Spindle center to column surface
mm
560
Rapid feed speed X
m/min
36/48
Rapid feed speed Y
m/min
36/48
Rapid feed speed Z
m/min
32
Cutting feed rate
mm/min
1-12000
Max table load
Kg
400
T-slot (N/W/D)
3/18/125
Spindle speed range
rpm
8000
Spindle diameter
mm
120
Spindle taper
/
BT40
Spindle motor power
Kw
5.5
Magazine capacity
T
20
Tool magazine type
Disc type
Max tool diameter
mm
Φ80-150/80-130
Max tool length
mm
300
Max tool weight
kg
6/7
Positioning accuracy
mm
±0.005
Repeatabiblity
mm
±0.003
Overall size
mm
2260*2700*2450
Net weight
kg
4200
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
About the supplier
Main products: Miller,CNC Machining center,Drilling machine
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 1999
Manufacturing exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 1999
