About this product
- Materials: Steel with chrome treatment
- Size: 7500mm*1000mm*1200mm
- Color: Blue&Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Steel with chrome treatment
- Size: 7500mm*1000mm*1200mm
- Color: Blue&Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Steel with chrome treatment |
|---|---|
| Size | 7500mm*1000mm*1200mm |
| Color | Blue&Yellow |
Product details
| Materials | Steel with chrome treatment |
|---|---|
| Size | 7500mm*1000mm*1200mm |
| Color | Blue&Yellow |
From the supplier
Product Name:
Steel Purlin Roll Forming Machine
Introduction:
C or Z shape purlin machine is made for steel structure frame. Through changing, this product line can make the change of the shape C or Z purlin, besides change different sizes of C or Z shape purlin. This change for shape and sizes of C/Z purlin can be realized by automatic mode, or manual adjusting mode.
C/Z shape purlin product line consists of uncoiling system, straightening system, hole punching system, shearing system, roll forming system, products support table, hydraulic system, automatic controlling system, and so on. It’s a high efficiency equipment of making purlin, which is suitable for current enterprises.
Working Flow:
Uncoiling→Sheet Guiding→Straightening &Levelling→Hole Punching→Measuring Length &Shearing→Roll Forming→Sheet to support table.
Main Technical Parameters:
Item
Parameters
Profile
C and Z purlin
Material
Type
Steel strip
（mm）Thickness
1.6-3.2
1.6-2.6
（Mpa）Yield stress
230-300
300-350
Max. Forming speed（m/min）
30
Roller material
GCR15; D2
Roller driven type
Hydraulic motor driven
Controller
PLC
Operation
Touch screen and button
Hydraulic system pressure（Mpa）
25
Hydraulic station motor power（KW）
7.5
Total power（KW）
30
Total weight（Kg）
About 12000
