Highway guard rails roll forming machine

10/10 fairsManufacturer
Highway guard rails roll forming machine
$11,11111$12,50000/ set FOB · ≈ converted from CNY
MOQ 1 set
Estimated landed cost
$15,204 / set
range $14,311$16,097 · total ≈ $1,520,424
See what’s included
FOB goods (100)
$1,180,556
Ocean freight + handling (5.0 CBM, volume guessed from price)
$1,300
US duty (3.5%)
$41,319
Section 301 tariff (25.0%)
$295,139
Customs fees (MPF/HMF)
$2,110

Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.

Verify from $29 · written report in 3 business days · 100% refund if unreachable

About this product

  • Size: 28*1.5*1.5m
  • Color: White red
  • Light source: Other
  • Certification: ISO
  • Usage: Other
  • Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
  • Made in: Jiangsu, China
Product details
Size28*1.5*1.5m
ColorWhite red
Light sourceOther
CertificationISO
UsageOther
From the supplier

Product descriptions


Two wave guard rails roll forming machine



Frame: Iron frame

Uncoiler: 5 tons uncoiler, electric

Forming station: 16

Driving type: Gearbox universal joint transmission

Main motor power: 55KW

Electrical system: Siemens control system

Punching system: 315 Hydraulic press machine

Material thickness: 2.0-2.75mm

Forming speed: 12-15m/min

Run out: 6m run out table

Others: Feeding machine with servo motor, servo motor:5.5kw, 7 rollers leveling



Technical process:

Uncoiler---leveling---feeding with servo motor and punching ---cutting---Automatic platform transportation---roll forming---run out table
