Roll-Type Die Cutting Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Roll-Type Die Cutting Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
From the supplier
ED-950 / 1200 automatic roll high-speed flat die-cutting machine on the basis of the ordinary model, through the redesign of the paper feeding structure and movement, improve the stability of the equipment, speed up the working speed of the equipment. This equipment is a professional equipment for die cutting, indentation, embossing coated paper, white cardboard, kraft paper and other paper. It is suitable for all paper packaging products such as paper cups, cartons, medicine boxes, handbags, etc. The machine adopts microcomputer control, servo drive positioning, AC frequency conversion, automatic counting, pneumatic locking plate, photoelectric correction, pneumatic clutch brake, thin oil centralized lubrication, automatic hydraulic loading and unloading, overload protection and unique worm gear transmission structure, which realizes smooth paper return and feeding, accurate positioning and neat material receiving. All the key parts and control system of the equipment are imported products, precision assembly, to ensure the stable die cutting pressure, accurate positioning, stable operation, safe and reliable.
Model
ED950
ED1200
Cutting Precision
±0.10mm
±0.10mm
Cutting Speed
100-150 times/min
90-140 times/min
Max. Cutting Size
950*540mm
1200*650mm
Applicable Base Paper Specifications
100-800gsm roll paper
100-800gsm roll paper
Air Source
0.5-0.7Mpa
0.5-0.7Mpa
Max. Pressure
250T
250T
Total Power
11kw
11kw
Weight
6500kgs
7800kgs
Overall Dimensions
4200*2100*1850mm
4200*2300*1850mm
From the supplier
ED-950 / 1200 automatic roll high-speed flat die-cutting machine on the basis of the ordinary model, through the redesign of the paper feeding structure and movement, improve the stability of the equipment, speed up the working speed of the equipment. This equipment is a professional equipment for die cutting, indentation, embossing coated paper, white cardboard, kraft paper and other paper. It is suitable for all paper packaging products such as paper cups, cartons, medicine boxes, handbags, etc. The machine adopts microcomputer control, servo drive positioning, AC frequency conversion, automatic counting, pneumatic locking plate, photoelectric correction, pneumatic clutch brake, thin oil centralized lubrication, automatic hydraulic loading and unloading, overload protection and unique worm gear transmission structure, which realizes smooth paper return and feeding, accurate positioning and neat material receiving. All the key parts and control system of the equipment are imported products, precision assembly, to ensure the stable die cutting pressure, accurate positioning, stable operation, safe and reliable.
Model
ED950
ED1200
Cutting Precision
±0.10mm
±0.10mm
Cutting Speed
100-150 times/min
90-140 times/min
Max. Cutting Size
950*540mm
1200*650mm
Applicable Base Paper Specifications
100-800gsm roll paper
100-800gsm roll paper
Air Source
0.5-0.7Mpa
0.5-0.7Mpa
Max. Pressure
250T
250T
Total Power
11kw
11kw
Weight
6500kgs
7800kgs
Overall Dimensions
4200*2100*1850mm
4200*2300*1850mm
