From the supplier
SKJG-90 Screw rod winding machine
I Description
This machine is used for coiling pipes, with spinning workbench and uniform heating temperature.
II Main technical data
Item
Data
Max. pipe diameter
3-90mm
Max. pipe length
2000mm( be adjustable)
Working speed
1600-2000 sections/8h
Air source
0.4-0.6MPa
Heating power
0.8kW x 6
Main motor driving power
3kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1800 x 2300 x 2400mm
Horizontal and Vertical wrapping machine
I Description
This machine is used for winding OPP, with CNC control.
II Main technical data
Item
Data
Max. rod diameter
15-60mm
Max. rod length
2500mm( be adjustable)
Heating power
0.8kW x 6
Main motor driving power
1.5kW + 0.75kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1520 x 1030 x 3030mm
Internal heat curing oven
I Description
This oven has internal volume(1 x 1.2 x 2 m), with dual fans, dual independent duct, and three-stage temperature control.
II Main technical data
Item
Data
Oven internal volume
1 x 1.2 x 2 m（be customization）
Max.temperature
280℃
Main motor driving power
15kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1500 x 1400 x 2500mm
Core knockout machine
I Main technical data
Item
Data
Max. knockout diameter
50 mm
Max. stroke
2000mm（be customization）
Core knockout capacity
2000-2300 sections/8h
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1500 x 1400 x 2500mm
Cutting machine
I Main technical data
Item
Data
Max. cutting diameter
40 mm
Max. cutting length
1600mm（be customization）
Feeding method
Pneumatic
Total power
3.2kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About2600 x 900 x 1600mm
Washing and polishing machine
I Main technical data
Item
Data
Max. rods diameter
40 mm
Max. cutting length
1600mm（be customization）
Polishing tension method
Manual
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About960 x 960 x 1000mm
Centreless grinder
I Main technical data
Item
Data
Max. rods diameter
40 mm
Grinding wheel
PSA350 x 125 x 127
Guide wheel
PSA350 x 125 x 127
Grinding wheel rotate speed
1870rpm
Guide wheel rotate speed
18-220rpm
Guide wheel swing diameter
Vertical: -2~ +40
Total power
9.5kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1550 x 1300 x 1405mm
From the supplier
SKJG-90 Screw rod winding machine
I Description
This machine is used for coiling pipes, with spinning workbench and uniform heating temperature.
II Main technical data
Item
Data
Max. pipe diameter
3-90mm
Max. pipe length
2000mm( be adjustable)
Working speed
1600-2000 sections/8h
Air source
0.4-0.6MPa
Heating power
0.8kW x 6
Main motor driving power
3kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1800 x 2300 x 2400mm
Horizontal and Vertical wrapping machine
I Description
This machine is used for winding OPP, with CNC control.
II Main technical data
Item
Data
Max. rod diameter
15-60mm
Max. rod length
2500mm( be adjustable)
Heating power
0.8kW x 6
Main motor driving power
1.5kW + 0.75kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1520 x 1030 x 3030mm
Internal heat curing oven
I Description
This oven has internal volume(1 x 1.2 x 2 m), with dual fans, dual independent duct, and three-stage temperature control.
II Main technical data
Item
Data
Oven internal volume
1 x 1.2 x 2 m（be customization）
Max.temperature
280℃
Main motor driving power
15kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1500 x 1400 x 2500mm
Core knockout machine
I Main technical data
Item
Data
Max. knockout diameter
50 mm
Max. stroke
2000mm（be customization）
Core knockout capacity
2000-2300 sections/8h
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1500 x 1400 x 2500mm
Cutting machine
I Main technical data
Item
Data
Max. cutting diameter
40 mm
Max. cutting length
1600mm（be customization）
Feeding method
Pneumatic
Total power
3.2kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About2600 x 900 x 1600mm
Washing and polishing machine
I Main technical data
Item
Data
Max. rods diameter
40 mm
Max. cutting length
1600mm（be customization）
Polishing tension method
Manual
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About960 x 960 x 1000mm
Centreless grinder
I Main technical data
Item
Data
Max. rods diameter
40 mm
Grinding wheel
PSA350 x 125 x 127
Guide wheel
PSA350 x 125 x 127
Grinding wheel rotate speed
1870rpm
Guide wheel rotate speed
18-220rpm
Guide wheel swing diameter
Vertical: -2~ +40
Total power
9.5kW
Electirc supply
380VAC, 3phase, 50HZ
Machie dimension
About1550 x 1300 x 1405mm
