Medium-Speed Paper Cup Forming Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Medium-Speed Paper Cup Forming Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
From the supplier
ED-122D paper cup forming machine is improved on plain paper cup machine to greatly improve the entire mechanical strength and stability. The machine can produce single-sided or double-sided PE coated drink cups, ice cream cups and other conical vessels through continuous process of oil injection, bottom flushing, heating, knurling, hemming and waft. The machine adopting hot blowing device and high-speed precision intermittent divider is featured by precision and reliability and is a preferred product for renewal of paper cup machine manufacturing industry.
Model
ED-122D
Cup size
6-22oz
Speed
60-120pcs/min
Material paper
160-350g/m2 Single side & double sides PE coating paper
Cup mouth diameter
60-90mm
Cup bottom diameter
40-60mm
Height
60-180mm
Bottom depth
5-10mm
Main motor power
1.5kw
Energy consumption
6-6.5kw/h
Total power
11.5kw
Air source
0.4m3/min, 0.5-0.8Mpa
Weight
2200kgs
Overall Dimensions
1750mm*1350mm*1850mm
From the supplier
ED-122D paper cup forming machine is improved on plain paper cup machine to greatly improve the entire mechanical strength and stability. The machine can produce single-sided or double-sided PE coated drink cups, ice cream cups and other conical vessels through continuous process of oil injection, bottom flushing, heating, knurling, hemming and waft. The machine adopting hot blowing device and high-speed precision intermittent divider is featured by precision and reliability and is a preferred product for renewal of paper cup machine manufacturing industry.
Model
ED-122D
Cup size
6-22oz
Speed
60-120pcs/min
Material paper
160-350g/m2 Single side & double sides PE coating paper
Cup mouth diameter
60-90mm
Cup bottom diameter
40-60mm
Height
60-180mm
Bottom depth
5-10mm
Main motor power
1.5kw
Energy consumption
6-6.5kw/h
Total power
11.5kw
Air source
0.4m3/min, 0.5-0.8Mpa
Weight
2200kgs
Overall Dimensions
1750mm*1350mm*1850mm
