Residual Current Circuit Breake
WENZHOU AOELEC ELECTRICAL CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Residual Current Circuit Breake
WENZHOU AOELEC ELECTRICAL CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: PA66
- Size: 83*71*36
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: PA66
- Size: 83*71*36
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | PA66 |
|---|---|
| Size | 83*71*36 |
| Color | Grey |
Product details
| Materials | PA66 |
|---|---|
| Size | 83*71*36 |
| Color | Grey |
From the supplier
Colorful box will be designed according to your requirement.">1 pcs/inner box,60 inner boxer/carton.
The carton is strong enough for sea and air shipment,
Colorful box will be designed according to your requirement. Port Ningbo/shanghai
eFunction and Feature:
Protection against earth/leakage current and residual current,fuction of isolation
Protection against fire hazard caused by insullation faults
Residual fault current indication
10kA high breaking capacity
Pin/fork type busbar terminal connection
Fire resistant plastic parts withstand abnormal heating and strong impact
Automatically disconnect the circuit when earth/leakage current occurs
or exceeds the rated sensitivity
Independent of power supply and line voltage,and free from external interference
Voltage fulctuation
35mm DIN rail mounting
Technical Data:
Rated current(In): 25,40,63,80,100A
Rated voltage(Un):230/240VAC,400/415VAC
Rated residual current:10mA,30mA,100mA,300mA
Number of poles: 2P 4P
Electrical endurance:4000cycles
Mechnical endurance:10000cycles
Cable termination:35mm2
Torque of screw:2.5Nm
IP degree:IP20
Standards:IEC/EN 61008-1
Catalog No. CTN Size:47.5x25.6x17.5cm
In(A)30mA100mA300mAQTY/BoxQTY/CTN Model No.Model No.Model No.PCSPCS25AAUR8 2P20AAUR8 2P 20AAUR8 2P 20A16040AAUR8 2P40AAUR8 2P 40AAUR8 2P 40A16063AAUR82P 63AAUR8 2P 63A AUR8 2P 63A16080AAUR8 2P 80AAUR8 2P 80AAUR8 2P 80A160
Dimensions(mm)
About us:
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates.
From the supplier
Colorful box will be designed according to your requirement.">1 pcs/inner box,60 inner boxer/carton.
The carton is strong enough for sea and air shipment,
Colorful box will be designed according to your requirement. Port Ningbo/shanghai
eFunction and Feature:
Protection against earth/leakage current and residual current,fuction of isolation
Protection against fire hazard caused by insullation faults
Residual fault current indication
10kA high breaking capacity
Pin/fork type busbar terminal connection
Fire resistant plastic parts withstand abnormal heating and strong impact
Automatically disconnect the circuit when earth/leakage current occurs
or exceeds the rated sensitivity
Independent of power supply and line voltage,and free from external interference
Voltage fulctuation
35mm DIN rail mounting
Technical Data:
Rated current(In): 25,40,63,80,100A
Rated voltage(Un):230/240VAC,400/415VAC
Rated residual current:10mA,30mA,100mA,300mA
Number of poles: 2P 4P
Electrical endurance:4000cycles
Mechnical endurance:10000cycles
Cable termination:35mm2
Torque of screw:2.5Nm
IP degree:IP20
Standards:IEC/EN 61008-1
Catalog No. CTN Size:47.5x25.6x17.5cm
In(A)30mA100mA300mAQTY/BoxQTY/CTN Model No.Model No.Model No.PCSPCS25AAUR8 2P20AAUR8 2P 20AAUR8 2P 20A16040AAUR8 2P40AAUR8 2P 40AAUR8 2P 40A16063AAUR82P 63AAUR8 2P 63A AUR8 2P 63A16080AAUR8 2P 80AAUR8 2P 80AAUR8 2P 80A160
Dimensions(mm)
About us:
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates.
