About this product
- Size: 详情咨询
- Color: For detailed consultation
- Structure: Single-Stage Pump
- Usage: Other
- Fuel: Other
- Standard: Standard
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Size: 详情咨询
- Color: For detailed consultation
- Structure: Single-Stage Pump
- Usage: Other
- Fuel: Other
- Standard: Standard
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Size | 详情咨询 |
|---|---|
| Color | For detailed consultation |
| Structure | Single-Stage Pump |
| Usage | Other |
| Fuel | Other |
| Standard | Standard |
| Theory | Centrifugal Pump |
| Application | FireCryogenicOther |
From the supplier
●ISO 2858 /5199 Standard
PISO Series is available in both a Heavy Duty Bare Shaft Pump and a Standard Duty Bare Shaft Pump, both fully manufactured and compliant to the international standards of ISO 2858 and ISO 5199.
Applications
Heavy industry
Water supply/distribution
- Fire protection
- Irrigation
- Condenser water
- Heating water
- HVAC
- Dewatering
Specifications
Inlet Diamater: 50~350mm
Out Diameter: 32~300mm
Capacity: Q up to 2000 m3/h (50Hz)
Head: H up to 150 m (50Hz)
Temperature: T up to 105°C
Working Pressure: 16Bar standard, 24Bar optional
Speed: n 2900/1450/980/740/580 rpm
3500/1750/1180/890/710 rpm
Materials
Casing: Cast iron
Impeller: Cast iron/Stainless steel304 as standard, Duplex stainless steel on request
Shaft: Stainless steel 420 standard,option SUS304,SUS316 ,Duplex steel
Two of Wear ring: Cast iron/Stainless steel
Bearing: Original Japanese Brand NTN as standard
Standard shaft sealing is mechanical seal ,Gland packing on request.
Shaft carried in grease life lubricated bearings (Oil lubrication , Grease lubrication available on request)
