High-Speed Impact Die-Cutting Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
High-Speed Impact Die-Cutting Machine
RUIAN E-DYNAMIC COMPLETE EQUIPMENT CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
From the supplier
ED900 high-speed automatic punching machine adopts automatic punching die-cutting technology, which integrates roll paper slitting, die-cutting and waste cleaning in the production of paper products. It eliminates the slitting link in the traditional process, and directly punching out the sample piece. Moreover, the sample piece incision is smooth, which greatly reduces the energy consumption and manpower, reduces the labor intensity of workers, and improves the utilization rate of paper. With the application of PLC micro electric control system and LCD visual human-machine interface, the working process of the whole machine is automated, and the working parameters and faults of the machine are dynamically displayed through the interface, so that the paper can be collected neatly and intelligently. It is an ideal equipment for disposable paper bowl, paper cup and other paper container slicing.
Model
ED900
Cutting Style
Punching style(for roll paper)
Cutting Speed
150-200times/min
Applicable Base Paper Specifications
125-350gsm roll paper
Width of Roll Paper
360-850mm
Diameter of Roll Paper
Max. 1500mm
Speed of Feeding Paper
Min. 35m/min(intermittent work)
Air Source
0.2m3/min, 0.5Mpa
Main Power
4kw
Total Power
8.5kw
Weight
3000kgs
Overall Dimensions
3000*1800*1700mm 700*700*1350mm
From the supplier
ED900 high-speed automatic punching machine adopts automatic punching die-cutting technology, which integrates roll paper slitting, die-cutting and waste cleaning in the production of paper products. It eliminates the slitting link in the traditional process, and directly punching out the sample piece. Moreover, the sample piece incision is smooth, which greatly reduces the energy consumption and manpower, reduces the labor intensity of workers, and improves the utilization rate of paper. With the application of PLC micro electric control system and LCD visual human-machine interface, the working process of the whole machine is automated, and the working parameters and faults of the machine are dynamically displayed through the interface, so that the paper can be collected neatly and intelligently. It is an ideal equipment for disposable paper bowl, paper cup and other paper container slicing.
Model
ED900
Cutting Style
Punching style(for roll paper)
Cutting Speed
150-200times/min
Applicable Base Paper Specifications
125-350gsm roll paper
Width of Roll Paper
360-850mm
Diameter of Roll Paper
Max. 1500mm
Speed of Feeding Paper
Min. 35m/min(intermittent work)
Air Source
0.2m3/min, 0.5Mpa
Main Power
4kw
Total Power
8.5kw
Weight
3000kgs
Overall Dimensions
3000*1800*1700mm 700*700*1350mm
