Main features of machine tools:

◆ Adopt a horizontal box-type bed and a tilted saddle design, which can take into account good thermal stability and cutting rigidity. The right-row or back-row chip discharge structure is adopted to achieve large chip discharge capacity and strong chip discharge ability, making users more flexible in the layout of the production workshop and facilitating full utilization of the factory space.

◆ The guide rail adopts roller track, which greatly improves the rigidity and service life of the guide rail. It has fast moving speed, good accuracy retention, simple maintenance, and is suitable for precision machining.

◆ The spindle component adopts a spindle unit structure, with strong rigidity and good thermal stability. The entire spindle component is dynamically balanced with high precision, and the maximum spindle speed can reach 4000rpm.

◆ The X/Z axis adopts Taiwan precision ball screws, which have fast moving speed, stable and high precision. The screws are all pre-stretched structure and have good cutting rigidity and thermal stability.

◆ There are two lubrication methods for this machine: grease lubrication and oil lubrication. The main shaft bearings and screw bearings are lubricated with high-quality high-speed long-term grease from Kruber, Germany, which has a long service life and is maintenance-free; the screw pairs and guide rail pairs adopt a thin oil automatic centralized lubrication system, which is fully and reliably lubricated.

◆ The standard configuration of the main motor adopts a high-performance spindle servo motor, with large spindle output torque, high speed and wide speed regulation range.

◆ This machine tool can flexibly match various manual chucks, hydraulic power chucks, and spring chucks according to customers 'actual needs, and can also make various special turning fixtures according to customers' parts.

◆ Adopt LED lighting: energy-saving, efficient and long life; adopt three-color working status indicator light: display the working status of the machine tool in real time, facilitating on-site visual management。

◆ This machine tool has compact structure, beautiful appearance, reliable fully enclosed protection performance, and smooth chip removal; high-strength tempered safety glass windows, bright work lights, humanized operating height, and comfortable operation.
