About this product
- Size: 430 x 220 x 200cm
- Color: Red
- Certification: ISO 9001
- Cylindrical grinder type: Other
- Abrasives: Grinding Wheel
- Processing object: Crank Shaft
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Shannxi, China
About this product
- Size: 430 x 220 x 200cm
- Color: Red
- Certification: ISO 9001
- Cylindrical grinder type: Other
- Abrasives: Grinding Wheel
- Processing object: Crank Shaft
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Shannxi, China
Product details
| Size | 430 x 220 x 200cm |
|---|---|
| Color | Red |
| Certification | ISO 9001 |
| Cylindrical grinder type | Other |
| Abrasives | Grinding Wheel |
| Processing object | Crank Shaft |
| Controlling mode | Artificial |
Product details
| Size | 430 x 220 x 200cm |
|---|---|
| Color | Red |
| Certification | ISO 9001 |
| Cylindrical grinder type | Other |
| Abrasives | Grinding Wheel |
| Processing object | Crank Shaft |
| Controlling mode | Artificial |
From the supplier
Crankshaft Grinding Machine
MODEL
UNIT
MQ8260C X 16
MQ8260C X 18
Max. work swing diameter x Max. work length
mm
Φ600 x 1600
Φ600 x 1800
Work diameter ground with steady rest
mm
Φ30 - Φ100
Φ30 - Φ100
Throw of crankshaft
mm
110mm
110mm
Max. work length
In 3-jaw chuck
mm
1400
1600
Between centers
mm
1600
1800
Max. work weight
kg
260
260
Headstock
Center height
mm
300
300
Work speed (3steps)
r/min
25/45/85
25/45/85
Wheel head
Max. cross movement
mm
185
185
Wheel head rapid approach and withdrawal
mm
100
100
Wheel feed per turn of cross feed head wheel
mm
1
1
Per grad. of cross feed head wheel
mm
0.005
0.005
Grinding wheel
Spindle speed (2steps)
r/min
740/890
740/890
Peripheral speed
m/sec
25.6-35
25.6-35
Wheel size (O.D x W x I.D)
mm
Φ900 x 32 x Φ305
Table
Table traverse per turn of head wheel
5.88mm (coarse)/1.68mm (fine)
Table swivel (taper 18/100)
5°
5°
Table swivel per grad of scale (taper 1:50)
10’
10’
Motor power
kw
9.82
9.82
Overall dimensions (L x W x H)
cm
417 x 204 x 158
417 x 204 x 158
Net Weight
kg
6000
6500
Gross Weight
kg
7500
8000
Packing dimension (L x W x H)
cm
430 x 220 x 205
520 x 220 x 205
