Main Features

1. Having reasonable structure, high rigidity, good looking and operating easily.
2. Transverse movement (front and rear) of work table is driven by servo motor and transmitted by Precision ball screw which can ensure precision, accurate positioning, automatic feed and fast forward and rewind functions.
3. Longitudinal movement (left and right) adopts a flat-type rail guide and controlled by servo motor.
4. Vertical movement is transmitted by precision shaped screw and driven by servo motor which can ensure precision, accurate positioning, automatic feed and rapid up and down function.
5. Adopting SIEMENS CNC SYSTEM which has high degree of automation.

Specifications Specification Unit MK1224 Max. workpiece to be ground(L*W*H) m 650*300 Max. travel of table(L*W) m 670*320 Table maximum cutting area(L*W) m 600*300 Number of T-Slot mm 1*14 Distance from table surface to spindle center mm 490 Wheel size(dia *width*bore) mm 300*30*φ75 Spindle speeds(50HZ) r/m 1440 Table longitudinal (left and right) speed (stepless) m/min 3~20 Table horizontal(before and after)the amount of feed Continuous(variable speed) mm/min 150 Intermittent(stepless) mm/Pass 0-5 The handwheel rotates mm 4 Hand wheel each grid mm 0.02 Vertical(up and down)feed wheel feed The handwheel rotates mm 2 Handwheel each grid mm 0.01 Spindle motor kw 4 Cooling motor w 40 Hydraulic motor kw 1.5 Working pressure Mpa 3 Oil tank capacity L 80 Max. capacity L/min 18 The machined surface of the base of parallelism mm 300/0.004 Surface roughness μm Ra0.32 Net weight T 1400 Packing size(L*W*H) mm 2000×1800×2050 Machine Details
