About this product
- Materials: PA66
- Size: 76*76*36
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: PA66
- Size: 76*76*36
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | PA66 |
|---|---|
| Size | 76*76*36 |
| Color | Grey |
From the supplier
Colorful box wil be designed according to your requirement">6 peaces/inner box.10 inner box/carton.
The carton is strong enough for air and sea shippment.
Colorful box wil be designed according to your requirement Port Ningbo/shanghai
Function and Feature:
AUSD switch disconnector allow breaking of equipment loads up to 600VAC
It's used for the following purposes:
main switch
switch for motors
saftey switch
disconnecton
Technical Date:
Rated current: 63,80,100,125A
Rated insulation voltage(Ui):800V
Rated thermal current at 40 °C (Ith):63,80,100,125A
Rated frequency:50/60Hz
Number of poles:3 poles
Utilization category:AC 21 A,AC, 22A,AC 23A
High electrical and mechanical endurance
Double break contacts
Mounting;35 DIN rail mounting,panel mounting,screw mounting
Cable termination:25~50mm2
protection: IP20
Standard: IEC60947-3
Catalog No. CTN Size:44.5x23.5x119cm
ModelRated CurrentQTY/BoxQTY/CTNAUSD-6363A440AUSD-8080A440AUSD-100100A440AUSD-125125A440
About us:
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our Switch Disconnector have KEMA,TUV,SEMKO,CB and CE certificates.
