ADDF8-63 6A~63A AFDD Isolating Arc Fault Interrupter 3P+N AC400/415V 50Hz IP20
Adidi Electric(Suzhou)Co.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
ADDF8-63 6A~63A AFDD Isolating Arc Fault Interrupter 3P+N AC400/415V 50Hz IP20
Adidi Electric(Suzhou)Co.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: plastic
- Size: mm
- Color: grey
- Arc-extinguishing medium: Other
- Installation: Other
- Certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Suzhou, Jiangsu, China
About this product
- Materials: plastic
- Size: mm
- Color: grey
- Arc-extinguishing medium: Other
- Installation: Other
- Certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Oceania, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Suzhou, Jiangsu, China
Product details
| Materials | plastic |
|---|---|
| Size | mm |
| Color | grey |
| Arc-extinguishing medium | Other |
| Installation | Other |
| Certification | Other |
| Poles number | Other |
Product details
| Materials | plastic |
|---|---|
| Size | mm |
| Color | grey |
| Arc-extinguishing medium | Other |
| Installation | Other |
| Certification | Other |
| Poles number | Other |
From the supplier
ADDF8-63, a three phase four wire Arc Fault Detection Device (AFDD), designed to reduce the risk of electric fire, can effectively detects electric arc faults, disconnects the affected circuit and offers complete protection in residential, non-residential building, energy sources, industry and infrastrutures. Installation of AFDD is strongly recommended in location with sleeping accomodations, place with fire risks due to big quantity flammable materials, place with combustible building materials, place with irreplaceable goods and beyond.
Technical Parameters
ContentTechnical ParametersRated voltage Ue, VAC400/415Rated frequency, Hz50Rated insulation voltage Ui, V500Rated impulse withstand voltage Uimp, V4000Rated current In, A6, 10, 16, 20, 25, 32, 40, 50, 63Number of poles3+NRated conditional short-circuit current Irc, A10000Rated making and breaking capacity I△m, A1000SCPD fuse10000Mechanical and electrical endurance, cycles4000Protection degreeIp20Ambient temperature, ℃-25~+40StandardsIEC 62606From the supplier
ADDF8-63, a three phase four wire Arc Fault Detection Device (AFDD), designed to reduce the risk of electric fire, can effectively detects electric arc faults, disconnects the affected circuit and offers complete protection in residential, non-residential building, energy sources, industry and infrastrutures. Installation of AFDD is strongly recommended in location with sleeping accomodations, place with fire risks due to big quantity flammable materials, place with combustible building materials, place with irreplaceable goods and beyond.
Technical Parameters
ContentTechnical ParametersRated voltage Ue, VAC400/415Rated frequency, Hz50Rated insulation voltage Ui, V500Rated impulse withstand voltage Uimp, V4000Rated current In, A6, 10, 16, 20, 25, 32, 40, 50, 63Number of poles3+NRated conditional short-circuit current Irc, A10000Rated making and breaking capacity I△m, A1000SCPD fuse10000Mechanical and electrical endurance, cycles4000Protection degreeIp20Ambient temperature, ℃-25~+40StandardsIEC 62606About the supplier
Main products: AC breaker, Circuit breaker, Small breaker ( low-voltage apparatus), Switch disconnector/Circuit breaker, Surge protector, Earth Leakage Circuit Breaker, GFCI (Ground Fault Circuit Interrupter), Signal Lamp Circuit Breaker
