About this product
- Materials: Metal
- Size: 2250x1588x2335mm
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Metal
- Size: 2250x1588x2335mm
- Color: Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Metal |
|---|---|
| Size | 2250x1588x2335mm |
| Color | Green |
Product details
| Materials | Metal |
|---|---|
| Size | 2250x1588x2335mm |
| Color | Green |
From the supplier
T7220B Vertical boring machine main features:
Mainly used to bore high accurate holes of cylinder body and engine sleeve and other accurate holes.
1. The table longitudinal and latitudinal moving device;
2. Boring measuring device;
3. Also provides optional digital readout for the table's longiland latimoving accessories to servo the users.
Main Specification: Model T7220B Max. boring Diameter F200mm Max. Boring Depth 500mm Spindle Speed Range 53-840rev/min Spindle Feed Range 0.05-0.20mm/rev Distance from Spindle Axis to Carriage Vertical plane 315mm Table Longitudinal Travel 900mm Table cross travel 100mm Machining accuracy Dimension Accuracy 1T7 Roundness 0.005 Cylindricity 0.02/300 Surface roughness Ra0.8-1.6 Overall Dimension (L×W×H) 2250x1588x2335mm N.W/G.W kg 3300/3800kg Machine Details:
From the supplier
T7220B Vertical boring machine main features:
Mainly used to bore high accurate holes of cylinder body and engine sleeve and other accurate holes.
1. The table longitudinal and latitudinal moving device;
2. Boring measuring device;
3. Also provides optional digital readout for the table's longiland latimoving accessories to servo the users.
Main Specification: Model T7220B Max. boring Diameter F200mm Max. Boring Depth 500mm Spindle Speed Range 53-840rev/min Spindle Feed Range 0.05-0.20mm/rev Distance from Spindle Axis to Carriage Vertical plane 315mm Table Longitudinal Travel 900mm Table cross travel 100mm Machining accuracy Dimension Accuracy 1T7 Roundness 0.005 Cylindricity 0.02/300 Surface roughness Ra0.8-1.6 Overall Dimension (L×W×H) 2250x1588x2335mm N.W/G.W kg 3300/3800kg Machine Details:
