S30B LED Ultrasound Scanner
I Specification:
Model
S30B Notebook LED Digital Ultrasound Scanner
Display mode
B;B/B;4B;B +M;M
Display size
12.1inch LED displayer
Image multiplying factor
3.5MHz/R60 convex array probe: x0.8;x1.0,x1.2,x1.5,x1.8, x2.0( 6 modes)x0.8;x1.0(display penetration depth)
E-zoom:
Magnify 2 times of real time image
Dynamic range
0~120db adjustable
Focus position
Dynamic electron focusing
Image proessing
8γcorrections, Point correlation, Frame correlation, Line correlation, Digital filting,Digital edge enhancement and pseudo color processing
According to the user's pattern style preference, the parameter will be set up automatically and saved ,Boot default this parameter. This default of parameter can aslo be modified in the menue.
Gray scale
256 levels
Frequency conversion
2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0Mhz
5 periods of frequency conversion
Frequency range applies
5.5MHz/6.0MHz/6.5MHz/7.0MHz/7.5MHz can match high frequency probe
Measuring function
Distance, circumference/area(method of ellipse,method of loci) ,volume,heart rate, gestational weeks, expected date of confinement and fetus weight,etc.
Annotation function:
Hospital name;patient’s name, age and gender; Body marks(with probe’s position);Full-screen character annotation;Real-time clock display
Puncture guide
3.5MHz convex array probe can display punture guide in B mode
Gain control
8segments TGC and overall gain can be adjusted respectively
Image polarity
Left and right flip; up and down flip
Capacity cine loop
Real time display 256 consecutive images which are moemorized successively
Image playback
Series playback or check one by one
Permanent storage
128 images
Output interface
USB port
Standard configuration
Ultrasound machine with 3.5Mhz convex array probe and power adapter
II.Standard Configuration:
1.One host machine
2.One convex array probe:F=3.5MHZ
3.One power adapter
4.11.1 V 5200MAH Li battery
5.USB port
6. Computer keyboard design, easy and fast operation
