Used in medical facilities. Suitable for inflammatory acne treatment, eliminate inflammation and promote skin wound healing.

Host: 525mm 610mm 1245mm (length, width and height)

Light source: 22mm 20mm 26mm (length, width and height)

Cantilever length: 70cm; cantilever lifting distance: 80cm-125cm;

effective area of irradiation

350cm2；

Irradiation distance

10cm±1cm

Output wavelength range

Red light 633nm ± 10nm; blue light 417nm ± 10nm;

effective irradiance

Scope of registration:

Red light: 200 mW / cm2; blue light 10 ~ 120 mW / cm2; yellow light 5 ~ 42 mW / cm2

Nominal value: error of ± 25%

Red light: 80 mW / cm2;

Red + blue: red light: 50 mW / cm2; blue light: 40 mW / cm2;

luminous power

Pure red light:> 60W; (measured 62.8W)

Red + blue: blue light> 42 W; red light> 30 W

display mode

LCD Display (8 " Color Touch LCD display)

Timed function

Ø The device has a timer, with a continuous working time of 99min, and the timing error is not greater than ± 2% of the set value;

Ø The equipment has the function of manually stopping the radiation output;

Ø The equipment has the function of temperature monitoring of the effective irradiation surface temperature, temperature monitoring range: 38~43℃, temperature measurement accuracy ± 3℃;

Ø The instrument has the preset function of the treatment plan;

Ø The instrument has a time mode;

Ø The instrument has the function of selecting light source alone and simultaneously (not for KN-7000A1-R, KN-7000A1-B, KN-7000A1-Y);

Ø The instrument has the manufacturers maintenance function;

Ø The instrument has the voice prompt function;

Ø The instrument can set the boot password;

Ø The instrument has the function of irradiation intensity regulation.

product features

l Suitable for acne treatment, eliminating inflammation, and promoting skin wound healing;

l Using high purity and high power integrated chip type solid cold light source, make the energy more concentrated, the light spot is more uniform, to ensure the treatment effect;

l The combination treatment of high-power red light and blue light treatment can realize rapid wound healing and anti-inflammation.

l Based on the fin type heat pipe heat dissipation system design, to ensure reliable heat dissipation, to ensure the life of light source;

l Using multi-dimensional damping axis design, the irradiation Angle is adjusted to be suitable for the treatment of different wound parts;

l Using the free telescopic cantilever system design, fully considering the ergonomic requirements, convenient operation, to maximize the clinical treatment environment;

l The bottom universal wheel is designed to facilitate indoor movement.

l Advanced contact-free temperature measurement device, real-time monitoring of the temperature of the irradiation site, with the overtemperature warning function, can eliminate safety risks to the greatest extent, to ensure that patients receive treatment in safe conditions.

l Increase the positioning indicator rod to ensure the effective irradiation distance, convenient operation, safe and reliable;

l Using 8 " full touch screen supplemented by humanized GUI design, make the operation more concise and smooth;

l It can store 4 commonly used treatment plans, eliminating the trouble of repeated setting. The main interface is selected with one key, which makes the operation more convenient.

l Dual-way light source can be treated sequentially or at the same time, each light source can also be set independently, the treatment is more flexible.

l Warm voice reminder, bring a relaxed and comfortable treatment experience for patients

l The light source intensity can be adjusted to meet different clinical needs;

l Power-on password protection, and the treatment process is safe and assured.
