XCMG Tower Crane used PLC control.Hoisting mechanism using high-power motor, lifting power stronger, more stable operation; Rotating mechanism block torque is relatively large, relative to other equivalent models, the torque is more powerful. Machine modeling and painting for specialized industrial design, beautiful appearance coordination. Platform, fence and escalator layout reasonable, to ensure good staff through the sex and security .

XGT7020-12 Tower Crane Performace and Charactics:
1. The most secure high-end construction lifting machinery benchmark.
2. The lifting performance is better than competitors.

3.New XGT-AMCS intelligent management system.
4. With the speed control function, the position accuracy is up to millimeter; ensure that the hoisting is smooth and accurate.
5. Quick disassembly, easy and efficient, the platforms and booms are quick-assembly structures, which save 3.2 hours for installation.

6.Parameter:

TypeXGT7020-12Basic height60MMax height240MLength70/65/60/55/50/45/40/35/30Max load12tTip load2/2.5/3.1/3.9/4.7/5.6/6.3/7.2/8.5Section size2000×2000×3000Section materialAngle steel/FoldingXGT7020-12ItemsMechanismSpeed(m/min)Rope capacityMotor(Kw)Hoist mechanism55JLF30A2 multiplying power0-90695M               >695M*554 multiplying power0-45Trolleying mechanism6JXF50-63m/min5.5Slewing mechanismJH12CT60-0.66r/min2×7.5TravellingRT0-25m/min4×4Main Supply380V(±10%)/50Hz*Gross Power(Excluding climbing and travelling):75.5Kw
