This product is used to hang on the wall to inflate tires, it applies to tire audible and visual end of the cycle signal indicators shop, 4S shops, garages, auto shops, gas stations and so on. It is an ideal inflation equipment.

Technicalparameter:

*Dimension                              1260*360*360 mm

*Power                                     100-240v ac  50/60 Hz

*Power consumption                23VA

*Temp range                            - 20  C-70  C

*Resolution                              1PSI/0.1bar/5kPa

*Accuracy                                +1 PSI/ 0.07 bar/7kPa

*Measurement units                 PSI/bar/kPa

*Max inlet air/nitrogen supply   217 PSI/15bar/1500kPa

*Opening range          5-174PSI/0.3-12bar/35-1200kPa

Specifications:

1.Comprehesive diagnostics and error reporting function

2.Large backlight LED display

3.Durable resistant mechanical switches

4.Suits for standard nitrogen bottle/direct nitrogen supply from generator/ air compressor

5.1 Nos*10 m/32.8 ft standard hose with single clip-on open type check

6.Automatic zero drift adjustment

7.Last setting remained

8.Audible and visual end of the cycle signal indicators

9.Auto-start inflation, self-diagnostic features

10.Controlled by microcomputer and high precision pressure sensor, can adjust tire pressure automatically

Package: 400*400*1290mm
