About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Cummins EFI engine (in compliance with three-stage emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high working efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions; reliable and accurate fuel injection system controls the injection volume in real time, making combustion more complete and fuel efficiency higher; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Name ITEM
flats
UNIT
technical specifications
Technical specifications
Operating weightKg
13890
PowerKW/rpm
86/2200
Rated bucket capacitym3
0.6
Total Length Amm
7762
Overall width (500 mm track) Width (500 mm track)Bmm
2510
Total Height Cmm
2983
Turntable width Dmm
2510
Height of cabin Emm
2825
Traveling speed (H/L)Km/hr
5.9/3.4
Swing speedrpm
13
GradeabilityDegree(%)
35（70%）
ground pressure
Ground pressure
Kgf/cm2
0.423
Maximum mining radiusA
8335 mm
Ground maximum digging radiusA’
8203 mm
Maximum mining depthB
5491 mm
Ground maximum digging depthB’
5288 mm
Maximum vertical digging depthC
4826 mm
Maximum digging heightD
8679 mm
Maximum unloading heightE
6174 mm
Minimum front radius of gyration Min. front turning radiusF
2605 mm
From the supplier
Cummins EFI engine (in compliance with three-stage emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high working efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions; reliable and accurate fuel injection system controls the injection volume in real time, making combustion more complete and fuel efficiency higher; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Name ITEM
flats
UNIT
technical specifications
Technical specifications
Operating weightKg
13890
PowerKW/rpm
86/2200
Rated bucket capacitym3
0.6
Total Length Amm
7762
Overall width (500 mm track) Width (500 mm track)Bmm
2510
Total Height Cmm
2983
Turntable width Dmm
2510
Height of cabin Emm
2825
Traveling speed (H/L)Km/hr
5.9/3.4
Swing speedrpm
13
GradeabilityDegree(%)
35（70%）
ground pressure
Ground pressure
Kgf/cm2
0.423
Maximum mining radiusA
8335 mm
Ground maximum digging radiusA’
8203 mm
Maximum mining depthB
5491 mm
Ground maximum digging depthB’
5288 mm
Maximum vertical digging depthC
4826 mm
Maximum digging heightD
8679 mm
Maximum unloading heightE
6174 mm
Minimum front radius of gyration Min. front turning radiusF
2605 mm
