Residual Current Circuit Breaker
SHANGHAI YONGJI ELECTRICAL CO.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Residual Current Circuit Breaker
SHANGHAI YONGJI ELECTRICAL CO.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 88
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Size: 88
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Size | 88 |
|---|
Product details
| Size | 88 |
|---|
From the supplier
Construction and Feature
Provides protection against earth fault/leakage current and function of isolation
High current rating up to 125A
Applicable to terminal and pin/fork type busbar connection
Fire resistant plastic parts endures abnormal heating and strong impact
Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds therated sensitivity.
Independent of power supply and line voltage, and free from external interference, voltage fluctuation.
Technical Data
Mode: electro-magnetic type, electronic type
Residual current characteristics: A, AC
Pole No.: 2, 4
Rated making and breaking capacity: 630A
Rated current(A): 25, 40, 63, 80, 100, 125
Rated voltage: AC 230(240)/400(415)
Rated frequency: 50/60Hz
Rated residual operating current I△n(A): 0.03, 0.1, 0.3, 0.5
Rated residual non operating current I△no: 0.5I△n
Rated conditional short-circuit current Inc: 6kA
Rated conditional residual short-circuit current I△c: 6kA
Tripping duration: instantaneous tripping≤0.1s
Residual tripping current range: 0.5I△n~I△n
Electro-mechanical endurance: Not less than 4000
From the supplier
Construction and Feature
Provides protection against earth fault/leakage current and function of isolation
High current rating up to 125A
Applicable to terminal and pin/fork type busbar connection
Fire resistant plastic parts endures abnormal heating and strong impact
Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds therated sensitivity.
Independent of power supply and line voltage, and free from external interference, voltage fluctuation.
Technical Data
Mode: electro-magnetic type, electronic type
Residual current characteristics: A, AC
Pole No.: 2, 4
Rated making and breaking capacity: 630A
Rated current(A): 25, 40, 63, 80, 100, 125
Rated voltage: AC 230(240)/400(415)
Rated frequency: 50/60Hz
Rated residual operating current I△n(A): 0.03, 0.1, 0.3, 0.5
Rated residual non operating current I△no: 0.5I△n
Rated conditional short-circuit current Inc: 6kA
Rated conditional residual short-circuit current I△c: 6kA
Tripping duration: instantaneous tripping≤0.1s
Residual tripping current range: 0.5I△n~I△n
Electro-mechanical endurance: Not less than 4000
