About this product
- Materials: Copper Aluminum
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia
- Made in: Henan, China
About this product
- Materials: Copper Aluminum
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia
- Made in: Henan, China
Product details
| Materials | Copper Aluminum |
|---|
From the supplier
The characteristics of photovoltaic cables are determined by their special insulation and sheath materials for cables, which we call cross-linked PE. After irradiation by an irradiation accelerator, the molecular structure of the cable material will change, thereby providing its performance in all aspects . Resistance to mechanical loads In fact, during installation and maintenance, the cable can be routed on the sharp edge of the roof structure, and the cable must withstand pressure, bending, tension, cross-tensile load and strong impact. If the cable jacket is not strong enough, the cable insulation will be severely damaged, which will affect the service life of the entire cable, or cause problems such as short circuits, fire, and personal injury.
The cross-sectional area of the DC cable is determined according to the following principles: the connection cable between the solar cell module and the module, the connection cable between the battery and the storage battery, and the connection cable for the AC load. 1.25 times the current; the connecting cable between the square array of solar cells and the connecting cable between the storage battery (group) and the inverter, the rated current of the cable is generally 1.5 times the maximum continuous working current of each cable.
The photovoltaic cable supporting other photovoltaic modules is exported to Europe, and the cable must comply with the TUV MARK certificate issued by TUV Rheinland of Germany.
ConstructionConductorConductorΦOuter ΦResistance Max.Current CarringconstructionCapacityn×mm2n/mmmmmΩ/KmA1×1.530/0.251.584.913.3301×2.550/0.252.025.457.98411×4.056/0.302.36.14.75551×6.084/0.303.427.23.39701×10.0142/0.304.5691.95981×16.0228/0.305.610.21.241321×25.0361/0.306.95120.7951761×35.0525/0.308.7413.80.5652181×50.0720/0.309.2414.80.33932801×70.0988/0.301116.90.2773501×95.01349/0.3012.518.70.214101×120.01691/0.3014.220.70.164480
