About this product
- Materials: aluminum
- Exports to: Mainland China, Africa, Southeast Asia, South Asia, Latin America, Other European Countries, Others
- Made in: Henan, China
About this product
- Materials: aluminum
- Exports to: Mainland China, Africa, Southeast Asia, South Asia, Latin America, Other European Countries, Others
- Made in: Henan, China
Product details
| Materials | aluminum |
|---|
Product details
| Materials | aluminum |
|---|
From the supplier
Application
This wire is suitable for use in spans on wood poles, transmission towers, and other structures where high tensile strength is not required. Applications range from extra high voltage (EHV) transmission lines to sub-service spans at distribution or utilization voltages on private premises.
AAC (all aluminum conductor) is the most economical bare overhead conductor due to its lighter weight. It offers easier handling during installation and use of simpler fittings. The wire is corrosion resistant due to its homogeneous construction.
CONSTRUCTION
- Aluminum alloy 1350 wires concentric lay stranded wrapped helically around a central wire. Each successive layer has six wires more than the previous underlying layer. Outer layer is right hand lay and reversed in successive layers.
ADDITIONAL STANDARDS
- ASTM B-230: Aluminum 1350-H19 wire for electrical purposes.
- ASTM B 231: Concentric Lay Stranded Aluminum 1350 Conductors.
- Application
This Product Suitable for Wooden Poles, Power Transmission Towers and Other Structures Not Requiring High Tensile Strength, Application Range from Extra High Voltage (EHV) Transmission Lines to Private Location Power Distribution
All-Aluminum Overhead Conductor: Lightweight, Economical with Excellent Corrosion Resistance
construction
Aluminum alloy 1350 wire, concentrically stranded on center steel wire, each layer 6 wires more than previous, outer layer right-hand lay alternating
Other Standards
ASTM B-230: Electrical Grade Aluminum 1350-H19 Wire
ASTM B231: concentric stranded aluminum 1350 conductor
AAC Standard ASTM B231
CodeSection AreaStrandingApprox. weightOverall DiameterBreaking LoadDC Resistance at 20℃Awgmm2mmkg/kmmmdaN≤Ω/kPeachbell613.297/1.554374.672492.1692Rose421.167/1.961585.893961.3624Iris233.617/2.474937.425970.8577Pansy142.397/2.7761178.337320.6801Poppy1/053.487/3.1191479.368730.539Aster2/067.427/3.50318610.5111000.4276Phlox3/085.037/3.93223411.813470.339Oxlip4/0107.237/4.41729613.2616980.2688Valerian250126.7119/2.93134914.5720620.2275Sneezewort250126.717/4.8034914.420070.2275Laurel266.8135.1619/3.0137315.0522000.2133Daisy266.8135.167/4.9637314.921410.2133Peony30015219/3.19341915.9724030.1896Tulip336.4170.4519/3.38147016.9126950.1691Daffodil350177.3519/3.44748917.2428040.1625Canna397.5201.4219/3.67355518.3631840.1431Goldentuft45022819/3.90962919.5534990.1264Syringa477241.6837/2.88266620.1938490.1193Cosmos477241.6819/4.02366620.1237080.1193Hyacinth500253.3537/2.95169820.6540350.1138Zinnia500253.3519/4.1269820.638880.1138Dahlia556.528219/4.34677721.7343270.1022Mistletoe556.528237/3.11477721.7943620.1022Meadowsweet60030437/3.23383822.6347030.0948Orchid636322.2537/3.3388823.3149850.0894Heuchera650329.3537/3.36690823.5650950.0875Flag700354.7161/2.7297824.4851460.0813
From the supplier
Application
This wire is suitable for use in spans on wood poles, transmission towers, and other structures where high tensile strength is not required. Applications range from extra high voltage (EHV) transmission lines to sub-service spans at distribution or utilization voltages on private premises.
AAC (all aluminum conductor) is the most economical bare overhead conductor due to its lighter weight. It offers easier handling during installation and use of simpler fittings. The wire is corrosion resistant due to its homogeneous construction.
CONSTRUCTION
- Aluminum alloy 1350 wires concentric lay stranded wrapped helically around a central wire. Each successive layer has six wires more than the previous underlying layer. Outer layer is right hand lay and reversed in successive layers.
ADDITIONAL STANDARDS
- ASTM B-230: Aluminum 1350-H19 wire for electrical purposes.
- ASTM B 231: Concentric Lay Stranded Aluminum 1350 Conductors.
- Application
This Product Suitable for Wooden Poles, Power Transmission Towers and Other Structures Not Requiring High Tensile Strength, Application Range from Extra High Voltage (EHV) Transmission Lines to Private Location Power Distribution
All-Aluminum Overhead Conductor: Lightweight, Economical with Excellent Corrosion Resistance
construction
Aluminum alloy 1350 wire, concentrically stranded on center steel wire, each layer 6 wires more than previous, outer layer right-hand lay alternating
Other Standards
ASTM B-230: Electrical Grade Aluminum 1350-H19 Wire
ASTM B231: concentric stranded aluminum 1350 conductor
AAC Standard ASTM B231
CodeSection AreaStrandingApprox. weightOverall DiameterBreaking LoadDC Resistance at 20℃Awgmm2mmkg/kmmmdaN≤Ω/kPeachbell613.297/1.554374.672492.1692Rose421.167/1.961585.893961.3624Iris233.617/2.474937.425970.8577Pansy142.397/2.7761178.337320.6801Poppy1/053.487/3.1191479.368730.539Aster2/067.427/3.50318610.5111000.4276Phlox3/085.037/3.93223411.813470.339Oxlip4/0107.237/4.41729613.2616980.2688Valerian250126.7119/2.93134914.5720620.2275Sneezewort250126.717/4.8034914.420070.2275Laurel266.8135.1619/3.0137315.0522000.2133Daisy266.8135.167/4.9637314.921410.2133Peony30015219/3.19341915.9724030.1896Tulip336.4170.4519/3.38147016.9126950.1691Daffodil350177.3519/3.44748917.2428040.1625Canna397.5201.4219/3.67355518.3631840.1431Goldentuft45022819/3.90962919.5534990.1264Syringa477241.6837/2.88266620.1938490.1193Cosmos477241.6819/4.02366620.1237080.1193Hyacinth500253.3537/2.95169820.6540350.1138Zinnia500253.3519/4.1269820.638880.1138Dahlia556.528219/4.34677721.7343270.1022Mistletoe556.528237/3.11477721.7943620.1022Meadowsweet60030437/3.23383822.6347030.0948Orchid636322.2537/3.3388823.3149850.0894Heuchera650329.3537/3.36690823.5650950.0875Flag700354.7161/2.7297824.4851460.0813
