About this product
- Materials: Metal
- Size: 2000x1250x1400mm
- Color: Blue and White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Metal
- Size: 2000x1250x1400mm
- Color: Blue and White
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Metal |
|---|---|
| Size | 2000x1250x1400mm |
| Color | Blue and White |
From the supplier
1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting.
2. To planing inclined plane, thereby expanding the scope of use.
3. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
4. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
5. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
6. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
Main Specification: Specification BC6050 Maximum planing length 500mm Maximum distance from the bottom of the working table 370mm lateral travel 525mm Vertical stroke 270mm Tool frame travel 120mm Sleeper reciprocating times (per minute) 14/20/28/40/56/80 Main motor power 3W The maximum size(width*thickness)of the handle 20×30mm The size of the T groove in the center of the worktable 18mm Angle of rotation ±60°(tool post) Workbench size 440×360mm Shape size 2000×1250×1400mm Mechine tool weight (about) 1650/1760KG Package dimensions 2000×1300×1600mm Machine Details:
