About this product
- Materials: low-hydrogen potassium type coating
- Size: 2.0mm,2.5mm,3.2mm,4.0mm,5.0mm
- Color: grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Hebei, China
About this product
- Materials: low-hydrogen potassium type coating
- Size: 2.0mm,2.5mm,3.2mm,4.0mm,5.0mm
- Color: grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Hebei, China
Product details
| Materials | low-hydrogen potassium type coating |
|---|---|
| Size | 2.0mm,2.5mm,3.2mm,4.0mm,5.0mm |
| Color | grey |
Product details
| Materials | low-hydrogen potassium type coating |
|---|---|
| Size | 2.0mm,2.5mm,3.2mm,4.0mm,5.0mm |
| Color | grey |
From the supplier
J506
GB：E5016
AWS：E7016
Applications：Used for welding medium-carbon steel and low-alloy steel structures, such as 16Mn, 09Mn2Si and A, B, D and E steel for ships, and also used for welding on thick plates and hard-to-weld carbon steel structures.
J506
According with GB E5016
Corresponding with AWS E7016
Introduction: J506 is a kind of electrode with low-hydrogen potassium type coating. AC/DC. All-position welding. It has excellent welding performance, stable arc, fewer spatters and good slag detachability. The deposited metal has excellent mechanical properties, crack-resistance and good low temperature impact toughness.
Applications: Used for welding medium-carbon steel and low-alloy steel structures, such as 16Mn, 09Mn2Si and A, B, D and E steel for ships, and also used for welding on thick plates and hard-to-weld carbon steel structures.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
P
Ni
Mo
Cr
V
Guarantee Value
≤0.12
≤1.60
≤0.75
≤0.035
≤0.040
≤0.30
≤0.30
≤0.20
≤0.08
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
ReL(Mpa)
A(%)
KV2(J)
KV2(J)
Guarantee Value
≥490
≥400
≥22
≥47(-20℃)
≥27(-30℃)
General Result
520~580
≥410
25~33
110~250
100~240
Diffusible Hydrogen Content in Deposited Metal: ≤8.0ml/100g(Glycerine Hydrogen Test)
X-ray Radiographic Inspection: ⅠDegree
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
60~100
80~140
110~210
160~230
Instructions:
1.The electrodes must be baked under 300~350℃ for an hour before welding and used as soon as baking is completed.
2.The stains on the weld, such as rust, oil stains, moisture, etc., must be cleared away before welding.
3.When welding, short arc must be used and stringer bead is suitable.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
