About this product
- Materials: stainless welding electrode E316-16
- Size: 2.5MM,3.2MM,4.0MM,5.0MM
- Color: grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia
- Made in: Hebei, China
About this product
- Materials: stainless welding electrode E316-16
- Size: 2.5MM,3.2MM,4.0MM,5.0MM
- Color: grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia
- Made in: Hebei, China
Product details
| Materials | stainless welding electrode E316-16 |
|---|---|
| Size | 2.5MM,3.2MM,4.0MM,5.0MM |
| Color | grey |
Product details
| Materials | stainless welding electrode E316-16 |
|---|---|
| Size | 2.5MM,3.2MM,4.0MM,5.0MM |
| Color | grey |
From the supplier
AWS：E316-16
Applications：Used for welding 0Cr18Ni12Mo2 stainless steel equipment working in organic acid and mineral acid (non-oxidizing acid) medium, and also used for welding dissimilar steel.
A202
According with GB E316-16
Corresponding with AWS E316-16
Introduction: A202 is a kind of low-carbon Cr18Ni12Mo2 stainless steel electrode with lime-titania type coating. Due to Mo added to the weld metal, it has excellent corrosion-resistance, heat-resistance and crack-resistance, especially suitable for chloride ion pitting corrosion-resistance. AC/DC. It has excellent welding performance.
Applications: Used for welding 0Cr18Ni12Mo2 stainless steel equipment working in organic acid and mineral acid (non-oxidizing acid) medium, and also used for welding dissimilar steel.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
P
Cu
Ni
Mo
Cr
Guarantee Value
≤0.08
0.5~2.5
≤0.90
≤0.030
≤0.040
≤0.75
11.0~14.0
2.00~3.00
17.0~20.0
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
≥520
≥30
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.0
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
40~80
50~100
70~130
100~160
140~200
Instructions:
1.The electrodes should be baked under 200-250℃ for an hour before welding.
2. D/C is preferred and the current should not be too strong.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
From the supplier
AWS：E316-16
Applications：Used for welding 0Cr18Ni12Mo2 stainless steel equipment working in organic acid and mineral acid (non-oxidizing acid) medium, and also used for welding dissimilar steel.
A202
According with GB E316-16
Corresponding with AWS E316-16
Introduction: A202 is a kind of low-carbon Cr18Ni12Mo2 stainless steel electrode with lime-titania type coating. Due to Mo added to the weld metal, it has excellent corrosion-resistance, heat-resistance and crack-resistance, especially suitable for chloride ion pitting corrosion-resistance. AC/DC. It has excellent welding performance.
Applications: Used for welding 0Cr18Ni12Mo2 stainless steel equipment working in organic acid and mineral acid (non-oxidizing acid) medium, and also used for welding dissimilar steel.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
P
Cu
Ni
Mo
Cr
Guarantee Value
≤0.08
0.5~2.5
≤0.90
≤0.030
≤0.040
≤0.75
11.0~14.0
2.00~3.00
17.0~20.0
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
≥520
≥30
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.0
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
40~80
50~100
70~130
100~160
140~200
Instructions:
1.The electrodes should be baked under 200-250℃ for an hour before welding.
2. D/C is preferred and the current should not be too strong.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
