About this product
- Materials: cast iron electrode composed of pure nickel core wire and strong reducibility graphite type coating.
- Size: 2..5mm,3.2mm,4.0mm,5.0mm
- Color: black color
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: cast iron electrode composed of pure nickel core wire and strong reducibility graphite type coating.
- Size: 2..5mm,3.2mm,4.0mm,5.0mm
- Color: black color
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | cast iron electrode composed of pure nickel core wire and strong reducibility graphite type coating. |
|---|---|
| Size | 2..5mm,3.2mm,4.0mm,5.0mm |
| Color | black color |
Product details
| Materials | cast iron electrode composed of pure nickel core wire and strong reducibility graphite type coating. |
|---|---|
| Size | 2..5mm,3.2mm,4.0mm,5.0mm |
| Color | black color |
From the supplier
Z308
GB：EZNi-1
AWS：ENi-C1
Applications：Repair welding on thin cast iron pieces and machined surfaces, such as some important gray cast iron pieces like cylinder head, engine bearers, guide rails of machine tools, gearwheel etc.
Z308
According with GB EZNi-1
Corresponding with AWS ENi-C1
Introduction: Z308 is a kind of cast iron electrode composed of pure nickel core wire and strong reducibility graphite type coating. It has excellent crack-resistance and mechanical property. Due to the expensive nickel cost, it’s the last choice after all other kinds of electrodes are not suitable. AC/DC.
Applications: Repair welding on thin cast iron pieces and machined surfaces, such as some important gray cast iron pieces like cylinder head, engine bearers, guide rails of machine tools, gearwheel etc.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
Ni
Fe
Total Quantity of Other Elements
Guarantee Value
≤2.00
≤1.00
≤2.50
≤0.030
≥90
≤8
≤1.00
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
≥520
≥35
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
50~100
70~120
110~180
160~190
Instructions:
1.The electrodes must be baked under about 150℃ for an hour before welding.
2. Hammering the weld gently, the stress in the welded areas can be eliminated and cracks can be avoided.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
