About this product
- Materials: Steel
- Size: 1736*729*1260mm
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Steel
- Size: 1736*729*1260mm
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Steel |
|---|---|
| Size | 1736*729*1260mm |
| Color | Yellow |
From the supplier
GS series electric pallet truck is professional solution for material handling in warehouse, it adopts the latest technology and renowned components to ensure the excellent performance. It is your best choice when it comes to price efficient material handling equipment. It can be widely used in factory, warehouse, medical, super market for material handling.
Main Feature
- Ergonomic design and compact structure increase the comfort during the operator’s operation, the dustproof and sealing structure prevent it from dust pollution damages and improve the service life.
- The stand platform help us the operator to drive and operate the pallet truck more convenient and optional EPS system is utilized for easier operation and less steering effort can highly increase the working efficiency.
- The maintenance free battery contributes to strong power and easier operation, it is suitable for most of the light and medium duty applications.
- Anti-reverse safety button mounted at the top of the handle reverses the truck direction to prevent the operator from being caught between the truck and obstacle on the unexpected occasions.
- Intelligent controller takes protection measures in case of over voltage, low voltage, over current, over temperature and short circuit occasions.
- Specially innovated speed deceleration system automatically reduces the travel speed when turning and greatly improve the loading stability, avoid the loading tipping over and ensures the safety of operation.
- Easy access emergency plug mounted on upright side of truck frame helps operator to take immediate action if any emergency occurs.
- Self-diagnostics provided direct fault code readout during operation and start up, which is easy for maintenance and service.
1
Model
FBT20
2
Power Type
Battery
3
Operator Type
Pedestrian
4
Rated Capacity
Q
t
2
5
Load Center
C
mm
600
6
Front Overhang
X
mm
965
7
Wheelbase
Y
mm
1372
8
Service Weight
kg
470
Dimension Parameter
9
Lift Height
h3
mm
120
10
Height of tiller in drive position min./max.
h14
mm
900/1260
11
Height Lowered
h13
mm
85
12
Overall Length
l1
mm
1736
13
Length to face of forks
l2
mm
587
14
Overall Width
b1
mm
729
15
Fork Dimensions
s/e/l
mm
90/173/1150
16
Distance Between Fork-arms
b5
mm
54/685
17
Ground Clearance / Centre of Wheelbase
m2
mm
25
18
Aisle Width for Pallets 800*1200 Lengthway
Ast
mm
2234
19
Turning Radius
Wa
mm
1570
Performance Parameter
20
Travel(Loaded/Unloaded)
km/h
6.0/6.0
21
Lifting(Loaded/Unloaded)
mm/s
27/35
22
Lowing(Loaded/Unloaded)
mm/s
42/27
23
Max.Gradeability(Loaded/Unloaded)
%
6/10
24
Service Brake
Electromagnetic
Tires
25
Tires
PU
26
Tread Front
b10
mm
500
27
Tread Rear
b11
mm
367/512
Motor
28
Drive motor Rating S2 60 min
kw
1.3
29
Lift motor Rating at S3 15%
kw
0.8
30
Battery(Voltage/Capacity)
V/Ah
21/210
31
Battery Weight
kg
220
32
Type of Drive Control
AC-speed control
