DGS30/127L(C) LED mining lighting fixture
Zhejiang TORMIN Electrical Co.,Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
DGS30/127L(C) LED mining lighting fixture
Zhejiang TORMIN Electrical Co.,Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Materials: Aluminium alloy, Tempered glass
- Size: φ230x 218mm
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Aluminium alloy, Tempered glass
- Size: φ230x 218mm
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Aluminium alloy, Tempered glass |
|---|---|
| Size | φ230x 218mm |
| Color | Grey |
Product details
| Materials | Aluminium alloy, Tempered glass |
|---|---|
| Size | φ230x 218mm |
| Color | Grey |
From the supplier
Wattage: 20W to 45W
Suitable for Mine
Ex Code: Ex d I Mb
Ambient temp.: -20℃ to +40℃
CHINA Mining Safety Certificate， CHINA explosion proof certificate
Application
1. Idea to be used in underground tunnel, chamber, substations, pump room, parking lot in the mining filed.
Characteristics
1. It is made using a special aluminum housing, all exposed fasteners adopt 304 stainless steel. Using high-tech anti-corrosion surface treatment technology, suitable for long-term highly corrosive environment under coal mine.
2. A full range of high conductivity material accelerate convection cooling structure, effective guarantee long-term use in high temperature environments.
3. Optoelectronic integrated technology no dark spot, no ghosting, the average light efficiency of whole lamp can reach to 100 lm/W, energy-saving is 60% more than Metal Halide Lamp.
4. Universal AC-DC, power factor above 0.98.
5. Quick replay light source without welding.
6. Independent wiring chamber, safe and easy installation and maintenance.
7. Designed for Roadway Layout with ring mounted which can be connected in parallel.
Main Specification
Item
Technical Parameters
Input voltage range
90~264 VAC
Input frequency
50Hz/ 60Hz
Light source
LED
Service life
50000h
CRI
Ra 70（80 Optional）
CCT
5000K (3000K/4000K Optional)
Cable entry
G3/4"
Leading-in cable diameter
φ9mm~φ14mm
Dimension
φ230* 218mm（Ring Mounting）
218* 230* 268mm（Bracket）
Net weight
2.7Kg（Ring Mounting）
3.2Kg（Bracket）
Ordering reference
Ordering
reference
Wattage
Light output
Mounting Type
Space
height
ratio
Mounting
height
Equivalent to
High Pressure Mercury Lamp
DGS20/127L(C)-P
20W
1800lm
Ring Mounting
1.75
2~6m
50W
DGS30/127L(C)-P
30W
2600lm
70W
DGS45/127L(C)-P
45W
3400lm
100W
DGS20/127L(C)-S
20W
1800lm
Bracket
50W
DGS30/127L(C)-S
30W
2600lm
70W
DGS45/127L(C)-S
45W
3400lm
100W
From the supplier
Wattage: 20W to 45W
Suitable for Mine
Ex Code: Ex d I Mb
Ambient temp.: -20℃ to +40℃
CHINA Mining Safety Certificate， CHINA explosion proof certificate
Application
1. Idea to be used in underground tunnel, chamber, substations, pump room, parking lot in the mining filed.
Characteristics
1. It is made using a special aluminum housing, all exposed fasteners adopt 304 stainless steel. Using high-tech anti-corrosion surface treatment technology, suitable for long-term highly corrosive environment under coal mine.
2. A full range of high conductivity material accelerate convection cooling structure, effective guarantee long-term use in high temperature environments.
3. Optoelectronic integrated technology no dark spot, no ghosting, the average light efficiency of whole lamp can reach to 100 lm/W, energy-saving is 60% more than Metal Halide Lamp.
4. Universal AC-DC, power factor above 0.98.
5. Quick replay light source without welding.
6. Independent wiring chamber, safe and easy installation and maintenance.
7. Designed for Roadway Layout with ring mounted which can be connected in parallel.
Main Specification
Item
Technical Parameters
Input voltage range
90~264 VAC
Input frequency
50Hz/ 60Hz
Light source
LED
Service life
50000h
CRI
Ra 70（80 Optional）
CCT
5000K (3000K/4000K Optional)
Cable entry
G3/4"
Leading-in cable diameter
φ9mm~φ14mm
Dimension
φ230* 218mm（Ring Mounting）
218* 230* 268mm（Bracket）
Net weight
2.7Kg（Ring Mounting）
3.2Kg（Bracket）
Ordering reference
Ordering
reference
Wattage
Light output
Mounting Type
Space
height
ratio
Mounting
height
Equivalent to
High Pressure Mercury Lamp
DGS20/127L(C)-P
20W
1800lm
Ring Mounting
1.75
2~6m
50W
DGS30/127L(C)-P
30W
2600lm
70W
DGS45/127L(C)-P
45W
3400lm
100W
DGS20/127L(C)-S
20W
1800lm
Bracket
50W
DGS30/127L(C)-S
30W
2600lm
70W
DGS45/127L(C)-S
45W
3400lm
100W
