About this product
- Materials: Aluminium alloy, Tempered glass
- Size: φ300x 290mm
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Aluminium alloy, Tempered glass
- Size: φ300x 290mm
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Aluminium alloy, Tempered glass |
|---|---|
| Size | φ300x 290mm |
| Color | Grey |
From the supplier
Wattage: 100W to 240W
ZONE 1/ 2; ZONE 21/ 22
Temperature class: T1 to T6
IP Code: IP66
Ex Code: Ex db e IIC T3/T4 Gb
Ex tb IIIC T195℃/ T130℃ Db
Ambient temp.: - 50℃ to +40℃/55℃
ATEX IECEX CE ROHS Certificate
Application
1. Ideal to be used in the oilfield, chemical industry, offshore drilling platform, steel industry, petroleum, etc.
2. Gas explosive environment: Group IIA, IIB, IIC.
Characteristics
1. ATEX seamless led light is made using a special aluminum housing, all exposed fasteners adopt 304 stainless steel. Using high-tech anti-corrosion surface treatment technology, suitable for long-term highly corrosive environment of offshore oil platforms, oil drilling platform, chlor-alkali, vulcanization cyanide, etc.
2. A full range of high conductivity material accelerate convection cooling structure, effective guarantee long-term use in high temperature environments.
3. Variety of light distribution, variety of installation types, an effective solution to beautify workshop and device platform.
4. The shell is made of high-tech surface coating technology, corrosion resistant, waterproof and dust proof, suitable for harsh environments.
5. Optoelectronic integrated technology，no dark spot, no ghosting, energy-saving is 60% more than Metal Halide Lamp.
6. Taiwan Meanwell power supply or same quality power supply, power factor above 0.98, high reliability and long time service life.
7. Independent wiring chamber, safe and easy installation and maintenance.
8. Quick replace light source without welding
9. Intelligent control functions can be realized.( Dimming: 1-10VDC, PWM, Carrier, DALI, etc.)
Main specification
Item
Technical Parameters
Input voltage range
90~264VAC;
Input frequency
50Hz/ 60Hz
Light source
LED
Service life
50，000h
CRI
Ra 70 (80 Optional)
Color Temperature
5000K(3000K/4000K Optional)
Cable entry
M20,M25, G3/4",NPT1/2",NPT3/4"
Leading-in cable diameter
φ10mm~φ14mm
Dimension
φ300×290mm
Net weight (kg)
6.4 Kg
Ordering reference
Ordering
reference
Wattage
Light output
Space
height
ratio
Mounting
height
Equivalent to
High Pressure Mercury Lamp
BC9307P-L100
100W
>11200lm
0.7~1.4
8~12m
250W
BC9307P-L120
120W
>12900lm
>250W
BC9307P-L150
150W
>16400lm
10~15m
400W
BC9307P-L180
180W
>18900lm
>400W
BC9307P-L200
200W
>23000lm
>400W
BC9307P-L240
240W
>28000lm
15~25m
600W~800W
