BC5402A LED explosion proof linear
Zhejiang TORMIN Electrical Co.,Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
BC5402A LED explosion proof linear
Zhejiang TORMIN Electrical Co.,Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Aluminum alloy, PC
- Size: 700(L)(20W~40W)or 1150(L)(60W~80W)×182(W)×68(H)
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Aluminum alloy, PC
- Size: 700(L)(20W~40W)or 1150(L)(60W~80W)×182(W)×68(H)
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Aluminum alloy, PC |
|---|---|
| Size | 700(L)(20W~40W)or 1150(L)(60W~80W)×182(W)×68(H) |
| Color | Grey |
Product details
| Materials | Aluminum alloy, PC |
|---|---|
| Size | 700(L)(20W~40W)or 1150(L)(60W~80W)×182(W)×68(H) |
| Color | Grey |
From the supplier
Wattage: 20W to 80W
ZONE 1/ 2; ZONE 21/ 22
Temperature class: T1 to T6
IP Code: IP66
Certification: II 2G Ex eb mb op is IIC T6/T5/T4 Gb
II2D Ex tb op is IIIC T80 ℃/ T95 ℃/ T130 ℃ Db
Ambient temp: -40℃ to +40℃/55℃
ATEX IECEX, CNEX, CE, ROHS Certification
Application
Suitable for oil production platform, oil refining platform, living platform,
hazardous chemicals ships, shore machines and other hazardous areas.
1. Seawater resistant, anodized aluminum housing.
2. Flexible light exit cover, soft and comfortable light.
3. The whole lighting effect is about 110 lm/W.
4. Ship-level anti-vibration test.
5. Outdoor light diffusion material translucent cover, strong weather resistance.
6. Independent junction box design, convenient wiring, can be used in parallel with multiple lamps.
7. Exposed fasteners are all made of 304 stainless steel (Ocean platform requires custom 316 stainless steel).
Input Voltage
108~264vac(20~60W); 186~264VAC(80W) 50Hz / 60Hz
CCT
5000K(3000K/ 4000K optional)
Light Efficacy
110lm/W(20W~40W); 105lm/W(60W~80W)
Screw Thread
NPT3/4", M20, M25, NPT1/2"
Number of cable inlets
1~2
Dimension
700×182×68mm(20W~40W); 1150×182×68（60W~80W）
Net Weight
3.2Kgs(20W/ 30W);3.4Kgs(40W); 4.5Kgs(60W); 4.7Kgs(80W)
From the supplier
Wattage: 20W to 80W
ZONE 1/ 2; ZONE 21/ 22
Temperature class: T1 to T6
IP Code: IP66
Certification: II 2G Ex eb mb op is IIC T6/T5/T4 Gb
II2D Ex tb op is IIIC T80 ℃/ T95 ℃/ T130 ℃ Db
Ambient temp: -40℃ to +40℃/55℃
ATEX IECEX, CNEX, CE, ROHS Certification
Application
Suitable for oil production platform, oil refining platform, living platform,
hazardous chemicals ships, shore machines and other hazardous areas.
1. Seawater resistant, anodized aluminum housing.
2. Flexible light exit cover, soft and comfortable light.
3. The whole lighting effect is about 110 lm/W.
4. Ship-level anti-vibration test.
5. Outdoor light diffusion material translucent cover, strong weather resistance.
6. Independent junction box design, convenient wiring, can be used in parallel with multiple lamps.
7. Exposed fasteners are all made of 304 stainless steel (Ocean platform requires custom 316 stainless steel).
Input Voltage
108~264vac(20~60W); 186~264VAC(80W) 50Hz / 60Hz
CCT
5000K(3000K/ 4000K optional)
Light Efficacy
110lm/W(20W~40W); 105lm/W(60W~80W)
Screw Thread
NPT3/4", M20, M25, NPT1/2"
Number of cable inlets
1~2
Dimension
700×182×68mm(20W~40W); 1150×182×68（60W~80W）
Net Weight
3.2Kgs(20W/ 30W);3.4Kgs(40W); 4.5Kgs(60W); 4.7Kgs(80W)
