DAPAN PRECISION MACHINERY,vertical machining center,Machining
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
DAPAN PRECISION MACHINERY,vertical machining center,Machining
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: ·
- Color: ·
- Processing precision: Other
- Movement method: Other
- Certification: Other
- Numerical control: CNC/MNCNCOther
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America
About this product
- Size: ·
- Color: ·
- Processing precision: Other
- Movement method: Other
- Certification: Other
- Numerical control: CNC/MNCNCOther
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America
Product details
| Size | · |
|---|---|
| Color | · |
| Processing precision | Other |
| Movement method | Other |
| Certification | Other |
| Numerical control | CNC/MNCNCOther |
| Control method | Other |
| Process usage | CNC Non-Conventional Machine ToolsMetal-Cutting CNC Machine ToolsOther |
| Performance classification | Mid-Range CNC Machine ToolsEconomical CNC Machine ToolsOther |
Product details
| Size | · |
|---|---|
| Color | · |
| Processing precision | Other |
| Movement method | Other |
| Certification | Other |
| Numerical control | CNC/MNCNCOther |
| Control method | Other |
| Process usage | CNC Non-Conventional Machine ToolsMetal-Cutting CNC Machine ToolsOther |
| Performance classification | Mid-Range CNC Machine ToolsEconomical CNC Machine ToolsOther |
From the supplier
1
stroke
x-axis travel
600MM
2
y-axis travel
450MM
3
Z-axis stroke
450MM
4
workbench
Distance from table top to spindle nose
135-585MM
5
workbench area (length * width) 700*420MM6
T-shaped groove 14*3*125mm7
The workbench bears weight 250KG8
spindle
model
BT409
spindle speed
12000RPM
10
transmission mode
direct connection type
11
spindle motor
7.5kW
12
Spindle taper hole diameter
Ф120
13
feed
Three-axis moving speed
24m/min
14
workpiece cutting speed
0-10m/min
15
Three-axis linear guide rail configuration Rail width Number of sliders
X axis: 30*2mm
Y axis: 30*2mm
Z axis: 35*2mm
16
Three-axis ball screw
X axis: Φ32mm*16
Y axis: Φ32mm*16
Z axis: Φ32mm*16
17
accuracy
Three-axis positioning accuracy
0.005/300mm18
Three-axis repetitive positioning accuracy
0.003/300mm19
other
barometric demand6.5kg/cm2
20
Machine tool external size (length * width * height)
2100*2000*2500mm
21
machine weight
3800kg
22 CNC system Siemens/Baoyuan/MitsubishiNote: Due to the continuous research and development of our company's technology, if there are changes to the model parameters and technical specifications, the specific specifications will be subject to the time of business negotiation, and the technical parameters are for reference only.
From the supplier
1
stroke
x-axis travel
600MM
2
y-axis travel
450MM
3
Z-axis stroke
450MM
4
workbench
Distance from table top to spindle nose
135-585MM
5
workbench area (length * width) 700*420MM6
T-shaped groove 14*3*125mm7
The workbench bears weight 250KG8
spindle
model
BT409
spindle speed
12000RPM
10
transmission mode
direct connection type
11
spindle motor
7.5kW
12
Spindle taper hole diameter
Ф120
13
feed
Three-axis moving speed
24m/min
14
workpiece cutting speed
0-10m/min
15
Three-axis linear guide rail configuration Rail width Number of sliders
X axis: 30*2mm
Y axis: 30*2mm
Z axis: 35*2mm
16
Three-axis ball screw
X axis: Φ32mm*16
Y axis: Φ32mm*16
Z axis: Φ32mm*16
17
accuracy
Three-axis positioning accuracy
0.005/300mm18
Three-axis repetitive positioning accuracy
0.003/300mm19
other
barometric demand6.5kg/cm2
20
Machine tool external size (length * width * height)
2100*2000*2500mm
21
machine weight
3800kg
22 CNC system Siemens/Baoyuan/MitsubishiNote: Due to the continuous research and development of our company's technology, if there are changes to the model parameters and technical specifications, the specific specifications will be subject to the time of business negotiation, and the technical parameters are for reference only.
