BF-TD588 amateur UV band radio integrates advanced digital technology, delivers excellent dual band transmission capacity, dual frequency standby, clear audio, enhanced features, and offers high playability. Whether for daily communication or outdoor activity use, it provides ham radio operators with stable and efficient communication support.

User Friendly Design

The BF-TD588UV is built with high-quality engineering material and features a non-slip textured design that ensures a firm grip even in slippery or harsh environments. Equipped with a 1.77-inch display, full numeric keypad, and clear UI this radio brings simpler and more intuitive operation, further enhancing user experience.

Dual Standby

BF-TD588 is a dual-band amateur radio that features good communication effect, supports UHF and VHF single and dual standby switching, featuring excellent communication effectiveness. The UHF band delivers clear audio in urban areas communication due to its strong penetration capability, while the VHF band brings an extended communication range for communications in wilderness areas.

Large Storage Capacity

BF-TD588 supports 400 channels and 64 zones, enhancing communication stability and reliability, allowing flexible channel switches, and avoiding busy channel/interference issues. The address books can store up to 2000 contacts, enabling group management and facilitating touch calling.

APRS (Automatic Position Reporting System)

BF-TD588UV incorporates analog APRS functionality, allowing it to automatically upload personal information and transmit information in real time without resorting to the network connection. Providing reliable guarantees for operations in mountainous and complex terrain areas lacking communication network coverage, ensuring real-time monitoring of personnel's location, and securing personal safety.

MIC Audio Noise Reduction

BF-TD588UV incorporates analog APRS functionality, allowing it to automatically upload personal information and transmit information in real time without resorting to the network connection. Providing reliable guarantees for operations in mountainous and complex terrain areas lacking communication network coverage, ensuring real-time monitoring of personnel's location, and securing personal safety.

Multiple Encryptions

BF-TD588UV features advanced AES256/ARC4 encryption to encrypt audio and data signals, ensuring communication privacy and information security.

Multiple Mode Positioning

BF-TD588UV supports GPS, Beidou, GLONASS, and Galileo positioning, enabling precise real-time outdoor satellite real-time positioning. Coupled with voice call location display technology, the recipient's call interface can show the direction information of the caller.

Safety Warning and Monitoring

BF-TD588UV enables multiple alarms and personal safety monitoring， including on-key alert, work alone, and man down. Allowing automatic emergency alarm uploading to secure personal safety at first time, and nip risks in the bud.

VFO/MR Mode

The BF-TD588UV supports VFO/MR mode switch. When in VFO mode, rotate the channel encoder or directly input frequencies in the numeric keypad to adjust frequencies, and rotate the channel encoder to switch channels when in MR mode, providing convenience for users to switch channels based on communication requirements flexibly.

NOAA Broadcast

BF-TD588 supports NOAA weather forecasting and warning, allowing it to scan hazardous weather channels nearby and transmit to your area even without mobile phone services. When the weather emergency alert function is on, the radio will automatically push warnings from designated NOAA broadcast stations. This is particularly useful for hikers, climbers, campers, and other outdoor users.

Rich Functionality

The BF-TD588UV dual-band amateur digital radio is designed with extensive features catering to outdoor users, supporting weather forecasting, FM radio, 15-hour recording, etc. In outdoor settings, it's suitable for receiving broadcasts and weather updates. Additionally, it supports optional Bluetooth peripherals for a more user-friendly experience, handling communication needs with ease, making it the ideal choice for both outdoor activities and commuting.

Specifications

General Frequency Range(Optional) 136-174 MHz/400-480 MHz Mode DMR Channels 4000 Zones 64 Channel Spacing 12.5KHz/25KHz Working Voltage DC 7.4V (±20%) Battery Capacity 2000 mAh Average Battery Working Life(5/5/90) Digital 21 Hours; Analog 15 Hours Frequency Stability ±0.5ppm Antenna Impedance 50Ω Current RX: 300mA; TX: 800mA Display TFT，128*160RGB，1.77 inches Keypad 18 buttons on front Dimensions 58(L)*36(W)*121(H)mm Weight 288g(including battery) Recording 15 Hours Bluetooth (Optional) BT5.0 Transmitter Output Power ＜5W 4FSK Modulation 12.5kHz Only data:7K60FXD
12.5kHz Data and voice:7K60FXE FM Modulation 12.5 kHz:8K50F3E; Modulation Limitation ±2.5kHz @ 12.5kHz; FM Noise -40dB Emission Spurious -36 dBm≤1GHz/-30 dBm≥1GHz Adjacent Channel Power ≥60dB Frequency Response +1/-3 dB Free time slot power ≤-57dBm Digital Vocoder AMBE Receiver Digital Sensitivity 5% BER:0.22uV Analog Sensitivity 0.165uV (12dB SINAD) Intermodulation ≥65dB Adjacent Channel Selectivity ≥60dB Spurious Suppression ≥65 dB FM Noise -40dB Frequency Response +1/-3 dB Rated audio-frequency output power 0.5W Maximum audio-frequency output power 2W Rated Audio-frequency Distortion 3% (Typical) Harmonic suppression ≤-57dBm If Rejection ≤70dBm Co-Channel Rejection ≤70dBm Image Rejection ≤70dBm Conducted Radiation ≤-57dBm Spurious radiation ≤-57dBm Blocking ≤90dBm Satellite Positioning Horizontal Accuracy≤-2.5m(With good signal) TTFF(First Locate) Cold Boot < 1 Minute TTFF(First Locate)Hot Boot < 10 Seconds TTFF Recapture < 10 Seconds Environmental Specifications Working Temperature -20℃—+60℃ Storage Temperature -30℃—+85℃ ESD Protection ±5kV(Contact Discharge); ±8kV (Air Discharge) Moisture Proof MIL-STD-810G Shock& Vibration MIL-STD-810G Waterproof& Dustproof IP54
