The BF-TD920 U/V dual-band digital two-way radio is designed based on the DMR standard, with improved audio clarity, smooth communication, and user-friendly interface. It delivers enhanced safety, privacy, stability, and data transmission capacity to ensure timely information sharing and efficient response, as well as facilitates effective and organized command and dispatch in challenging scenarios.

UV Dual Band

BF-TD920 DMR radio supports U/V dual band and dual standby for enhanced flexibility. The UHF band is ideal for high-density urban areas due to its strong penetration capability, while the VHF band is well-suited for diffusing terrains like plains and wilderness areas. Enables users to switch freely between urban buildings and complex outdoor areas based on their specific requirements, which can meet various communication needs in different emergency scenarios.

Intelligent Noise Cancellation

BF-TD920 is equipped with a built-in noise reduction module, with adaptive microphone noise reduction technology to filter background noise and suppress feedback. This allows users to deliver clear audio even in noisy environments or adverse outdoor weather conditions.

Full Duplex Communication

BF-TD920 U/V dual-band radio incorporates a whole new full-duplex communication to enhance communication reliability and ensure timely response and efficient command and dispatch.

3-Level Regions

BF-TD920 supports 3-level regions setting and 3773 conventional storage channels, allowing manual zone switch and enabling swiftly cross-region reinforcement preparation, which enhanced management convenience, and guaranteed reliable communication for prompt response and cross-region communication.

Enhanced RF Capacity

With the conventional superheterodyne circuitry design, BF-TD920 brings superior transmission and reception, guaranteeing stable reception across expansive areas. It provides close-range, offline communication and reliable supports for communications in network disruption, limited coverage, and unforeseen natural disasters.

Military Standard

BF-TD920 UV has been undergone military standards and IP68 protection. The multiple reinforcement tests on the screen provide it with excellent resistance to impact, vibration, and solar radiation, enabling it to adapt to various harsh environments.

Multiple Security Alarms

The BF-TD920 DMR radio supports GPS, man down, lone worker, emergency alarm and one key emergency alarm solution to further secure personal safety.

Multiple Encryption

To further secure communication confidentiality, BF-TD920 supports multiple digital encryptions including XOR encryption, AES256, and ARC4 encryption.

Rich Functions

The BF-TD920U/V dual-band radio fully considers user experience with series of user-friendly designs. Its 2.0-inch semi-transparent screen delivers excellent visual clarity and the full keyboard layout further simplifies operations. Equipped with LED flashlight, stealth mode, TTS, large capacity battery, optional Bluetooth, and recording to enhance communication experience. Additionally, it seamlessly supports conventional mode, Ad hoc, BelFone dispatch system, etc., which significantly enhanced management convenience and efficiency.

Specifications

General Frequency Range(Optional) 136-174 MHz; 400-480 MHz Channels 3773 Zones 3000 Channel Spacing 12.5KHz/25KHz Operating Voltage DC 7.4V (±20%) Battery Capacity 2500 mAh Average Battery Working Hour (5/5/90) 16 Hours(Analog); 21 Hours(Digital) Frequency Stability ±1ppm Antenna Impedance 50Ω Dimensions 66(L)*35(W)*145(H)mm Weight 540g (Including Battery) Recording (Optional) 400 Hours Bluetooth (Optional) BT5.0 Transmitter Output Power Low Power:1W; High Power:4W 4FSK Modulation 12.5kHz only data:7K60FXD FM Modulation 12.5 kHz:8K50F3E; 12.5kHz data and voice:7K60FXE Modulation Limitation ±2.5kHz @ 12.5kHz; FM Noise -40dB Spurious Emission -36 dBm≤1GHz/-30 dBm≥1GHz Adjacent Channel Power ≥60dB Frequency Response +1/-3 dB Audio Distortion 3% Digital Vocoder AMBE Receiver Digital Sensitivity 5% BER:0.22uV Analog Sensitivity 0.22uV (12 dB SINAD) Intermodulation ≥60dB Adjacent Channel Selectivity ≥60dB Spurious Suppression ≥65 dB FM Noise -40dB Frequency Response +1/-3 dB Rated Audio Output 500mW Maximum Audio Output 1.1W Rated Audio Distortion 3% (typical) Conducted Radiation -57dBm Positioning Precision Horizontal Accuracy ≤-10m(with good signal) TTFF (First Location)Cold Boot < 1 minute TTFF(First Location) Hot Boot < 10 second Environmental Specifications Working Temperature -20℃—+60℃ Storage Temperature -30℃—+85℃ Moisture Proof By MIL-STD-810C/D/E/F/G Vibration & Shock By MIL-STD-810C/D/E/F/G Waterproof & Dustproof IP68
